BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit
BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit
Hero image 0 of BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit, 0 of 6

BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit

(No ratings yet)

Key item features

  • Flexible Power: Features an isolated 5V power supply, shareable with an MCU, or utilizing the on-board 5V supply, with an input voltage range of 5.5V to 27V.
  • Enhanced Protection: Provides 5V isolation for the MCU, effectively safeguarding it, and includes a 5V power indicator on the board for convenience.
  • Motor Control: Supports forward and reverse motor operation with two PWM input frequencies up to 25kHz, and includes two heat flow error signal outputs.
  • Simplified Interface: Requires only four lines from the MCU (GND, 5V, PWM1, PWM2) for control, simplifying integration.
  • Robust Specifications: Operates with an input voltage of 6V-27V, handles a maximum current of 43A, and supports PWM or level control methods with a 0-100% duty cycle.
  • Detailed Inputs: Offers specific input ports including RPWM and LPWM for forward/reverse signals, R_EN and L_EN for drive enable, and R_IS and L_IS for current alarm outputs.
Generated by AI

Specs

Input voltage, 6 VBrand, UnbrandedHeight, 3 cmHas written warranty, No

About this item

Product details

Input voltage: 6V-27V
Maximum current: 43A
Input level: 3.3-5V
Control method: PWM or level
Duty cycle: 0-100%
Input port:
1.RPWM: forward level or PWM signal input, active high
2.LPWM: Reverse level or PWM signal input, active high
3.R_EN: forward drive enable input, high-level enable, low level
4.L_EN: Reverse drive enable input, high-level enable, low level
5.R_IS: forward drive current alarm output
6.L_IS: Reverse drive current alarm output
7.VCC: +5 V power output, 5V power supply connection with the microcontroller
8.GND: signal common low end
Colour:Photo Color
Material: ABS
Size: 5 x 5 x 3cm

Package Contents:
1 x Motor Driver Module

Only the above package content, other products are not included.
Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
  • Isolated chip 5V power supply (can be shared with the MCU 5V), can also use the on-board 5V supply; the supply voltage 5.5V to 27V.
  • Voltage indication of motor driver output end; can solder heat sink.
  • 5V isolate with MCU, and effectively protect MCU; 5V power indicator on board.
  • to reverse the motor forward, two PWM input frequency up to 25kHZ; two heat flow passing through an error signal output.
  • Just need four lines from MCU to driver module (GND. 5V. PWM1. PWM2); isolation chip 5 V power supply (can share with MCU 5 V).
info:
