BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit
(No ratings yet)
Key item features
- Voltage indication of motor driver output end; can solder heat sink.
- Just need four lines from MCU to driver module (GND. 5V. PWM1. PWM2); isolation chip 5 V power supply (can share with MCU 5 V).
- to reverse the motor forward, two PWM input frequency up to 25kHZ; two heat flow passing through an error signal output.
- Isolated chip 5V power supply (can be shared with the MCU 5V), can also use the on-board 5V supply; the supply voltage 5.5V to 27V.
- 5V isolate with MCU, and effectively protect MCU; 5V power indicator on board.
Specs
Input voltage, 6 V
Brand, Unbranded
Height, 3 cm
Has written warranty, No
Input voltage
6 V
Brand, Unbranded
Brand
Unbranded
Height, 3 cm
Height
3 cm
Has written warranty, No
Has written warranty
No
Similar items you might like
Based on what customers bought
Digital Stepper Driver, Dm556 Motor Driver $18.43
$1843current price $18.43Digital Stepper Driver, Dm556 Motor Driver
2Pcs BTS7960 43A High Power Motor Driver Module Smart Car Driver Module for Current Limit $17.10
$1710current price $17.102Pcs BTS7960 43A High Power Motor Driver Module Smart Car Driver Module for Current Limit
DC 6V 12V 24V DC Motor Forward and Reverse Controller 20A High Current with Limit Relay Driver Lifting Control Board P0 $8.47
$847current price $8.47DC 6V 12V 24V DC Motor Forward and Reverse Controller 20A High Current with Limit Relay Driver Lifting Control Board P0
BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit $10.44
$1044current price $10.44BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit
TB6612FNG High Efficiency Double Motor Driver 1A Speed Control $9.99
$999current price $9.99TB6612FNG High Efficiency Double Motor Driver 1A Speed Control
L298N DC Motor Drive Controller Module, Mini 2.5A Dual H-Bridge PWM Speed Regulation Reversing Motor Driver Board for Arduino Smart Car Robot DIY Projects $7.34
$734current price $7.34L298N DC Motor Drive Controller Module, Mini 2.5A Dual H-Bridge PWM Speed Regulation Reversing Motor Driver Board for Arduino Smart Car Robot DIY Projects
Reduced price, TB6612FNG Double Motor Drive Module 1A High Efficiency Small Design for Microcontroller Robotics Projects $8.16 Was $9.12
Reduced price
$816current price $8.16, Was $9.12$9.12TB6612FNG Double Motor Drive Module 1A High Efficiency Small Design for Microcontroller Robotics Projects
BONROB L298N Motor Driver Controller Module, Dual H-Bridge DC & Stepper Motor Driver, 4 Count, 4 Pack $14.99
$1499current price $14.99BONROB L298N Motor Driver Controller Module, Dual H-Bridge DC & Stepper Motor Driver, 4 Count, 4 Pack
4X BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit $21.59
$2159current price $21.594X BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit
5pcs DRV8825 Stepper Motor Driver Module 4-Layer with Mini Heat Sink RP1.4 A4988 $10.80
$1080current price $10.805pcs DRV8825 Stepper Motor Driver Module 4-Layer with Mini Heat Sink RP1.4 A4988
PCA9685 16-Channel PWM Servo Driver Motor Drive Board Module IIC Interface for Robotic Controls, 10 Inches / 25.4 cm $10.58
$1058current price $10.58PCA9685 16-Channel PWM Servo Driver Motor Drive Board Module IIC Interface for Robotic Controls, 10 Inches / 25.4 cm
2X BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit $10.65
$1065current price $10.652X BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit
MKS OSC V1.0 Stepper Motor Drive Simple Controller Pulse PWM Signal Generator Module Speed Control 8-24V $7.89
$789current price $7.89MKS OSC V1.0 Stepper Motor Drive Simple Controller Pulse PWM Signal Generator Module Speed Control 8-24V
2Pcs BTS7960 43A High Power Motor Driver Module Smart Car Driver Module for Current Limit PCB Blue&Black,2 x BTS7960B H-bridge 43A High-Power Motor Driver Module $17.09
$1709current price $17.092Pcs BTS7960 43A High Power Motor Driver Module Smart Car Driver Module for Current Limit PCB Blue&Black,2 x BTS7960B H-bridge 43A High-Power Motor Driver Module
11 out of 5 Stars. 1 reviews1 out of 5 starsDC Brushless Motor Driver Board FOC Control Driver SVPWM Control DC 10-24V Module Replace Simple FOC Mini $9.78
$978current price $9.78DC Brushless Motor Driver Board FOC Control Driver SVPWM Control DC 10-24V Module Replace Simple FOC Mini
AT8236 Dual-Channel Motor Driver Module with Onboard Regulator, 5.5-17V , 2 PWM Control, 3.3V Logic, 6A $15.43
$1543current price $15.43AT8236 Dual-Channel Motor Driver Module with Onboard Regulator, 5.5-17V , 2 PWM Control, 3.3V Logic, 6A
3X BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit $17.62
$1762current price $17.623X BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Current Limit
TB6612 FNG Motor Driver Module with Voltage Stabilization High Performance Ultra L298 Chip Car $14.71
$1471current price $14.71TB6612 FNG Motor Driver Module with Voltage Stabilization High Performance Ultra L298 Chip Car
L298N Driver Board Module L298 Stepper Motor Intelligence Car Robot Breadboard High Power Board for Robotics Car $8.52
$852current price $8.52L298N Driver Board Module L298 Stepper Motor Intelligence Car Robot Breadboard High Power Board for Robotics Car
BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Arduino Current Limit $10.99
$1099current price $10.99BTS7960 43A High Power Motor Driver Module/Smart Car Driver Module for Arduino Current Limit
About this item
Product details
Input voltage: 6V-27V
Maximum current: 43A
Input level: 3.3-5V
Control method: PWM or level
Duty cycle: 0-100%
Input port:
1.RPWM: forward level or PWM signal input, active high
2.LPWM: Reverse level or PWM signal input, active high
3.R_EN: forward drive enable input, high-level enable, low level off
4.L_EN: Reverse drive enable input, high-level enable, low level off
5.R_IS: forward drive current alarm output
6.L_IS: Reverse drive current alarm output
7.VCC: +5 V power output, 5V power supply connection with the microcontroller
8.GND: signal common low end
Colour:Photo Color
Material: ABS
Size: 5 x 5 x 3cm
Package Contents:
1 x Motor Driver Module
Only the above package content, other products are not included.
Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
Maximum current: 43A
Input level: 3.3-5V
Control method: PWM or level
Duty cycle: 0-100%
Input port:
1.RPWM: forward level or PWM signal input, active high
2.LPWM: Reverse level or PWM signal input, active high
3.R_EN: forward drive enable input, high-level enable, low level off
4.L_EN: Reverse drive enable input, high-level enable, low level off
5.R_IS: forward drive current alarm output
6.L_IS: Reverse drive current alarm output
7.VCC: +5 V power output, 5V power supply connection with the microcontroller
8.GND: signal common low end
Colour:Photo Color
Material: ABS
Size: 5 x 5 x 3cm
Package Contents:
1 x Motor Driver Module
Only the above package content, other products are not included.
Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
- Voltage indication of motor driver output end; can solder heat sink.
- Just need four lines from MCU to driver module (GND. 5V. PWM1. PWM2); isolation chip 5 V power supply (can share with MCU 5 V).
- to reverse the motor forward, two PWM input frequency up to 25kHZ; two heat flow passing through an error signal output.
- Isolated chip 5V power supply (can be shared with the MCU 5V), can also use the on-board 5V supply; the supply voltage 5.5V to 27V.
- 5V isolate with MCU, and effectively protect MCU; 5V power indicator on board.
