Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High and Low Level H/L Level Trigger Module Triggered Compatible with Arduino Raspberry Pi

Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High and Low Level H/L Level Trigger Module Triggered Compatible with Arduino Raspberry Pi

(No ratings yet)

Key item features

  • Input voltage: DC 5V, normally open interfaces, the max load of interface is AC 250V/10, DC 30V/10A.
  • SMD optocoupler isolation, strong driving ability, stable performance; trigger current 5mA.
  • With green power light, red relay status indicator light, can reflect the module's working condition directly.
  • The Module can be set by jumper high or low trigger.

Specs

Amps, 10 AInput voltage, 5 VBrand, TREEDIXFeatures, LED IndicatorSize, 2 ChannelHas written warranty, No

About this item

Product details

Maximum load: AC 250V/10A, DC30V/10A
SMD optocoupler isolation, strong driving ability, stable performance; trigger current 5mA
The module voltage 5V
Each channel module can be set high or low triggered by jumper
Fault-tolerant design, even if the control line is broken, the relay will not operate
Power indicator (green), relay state indicator (red)
Interface design user-friendly, all interfaces are available through the wiring terminal direct connection leads, very convenient
4 mounting bolts holes, hole 3.1mm, spacing 44.5mm * 35.5mm
Module Port:
DC+: DC power supply positive
DC-: DC power supply negative
IN1: Channel 1 signal trigger terminal
IN2: Channel 2 signal trigger terminal

Relay Output:
NC1: Channel 1 relay normally closed pin
COM1: Channel 1 relay common pin
NO1: Channel 1 relay normally opened pin
NC2: Channel 2 relay normally closed pin
COM2: Channel 2 relay common pin
NO2: Channel 2 relay normally opened pin

High And Low Level Trigger Option:
1. S1: It is option switch for channel 1 relay
2. S2: It is option switch for channel 2 relay

Package include:
2 x DC 5v 2 Channel Relay Board Modules

  • Input voltage: DC 5V, normally open interfaces, the max load of interface is AC 250V/10, DC 30V/10A.
  • SMD optocoupler isolation, strong driving ability, stable performance; trigger current 5mA.
  • With green power light, red relay status indicator light, can reflect the module's working condition directly.
  • The Module can be set by jumper high or low trigger.
