Hero image 0 of Timer Multifunction Delay Time Module Switch Control Relay Cycle Timer DC 12V, 0 of 6
Timer Multifunction Delay Time Module Switch Control Relay Cycle Timer DC 12V
(No ratings yet)
Key item features
- New upgrades to simplify, meeting the users\u0027 needs
- Increase the power supply anti-reverse function
- LED digits display, intelligent control, time relay/delay function
- The use of opto isolated input and output, enhanced anti-jamming capability and consumption
- The last setting parameters can be memorized after power off
- Power saving function, one-key , can turn off the display
- The use of opto isolated input and output, enhanced anti-jamming capability and consumption.Power saving function, one-key , can turn off the display
- The last setting parameters can be memorized after power off.To ensure stability, industrial grade PCB board
- New upgrades to simplify, meeting the users\u0027 needs. Power saving function, one-key , can turn off the display
- Increase the power supply anti-reverse function. To ensure stability, industrial grade PCB board
- New upgrades to simplify, meeting the users\u0027 needs.Increase the power supply anti-reverse function
Specs
Amps, 10 A
Brand, Andoer
Features, LED Indicator
Assembled product weight, 1 lb
Has written warranty, No
Amps
10 A
Brand, Andoer
Brand
Andoer
Features, LED Indicator
Features
LED Indicator
Assembled product weight, 1 lb
Assembled product weight
1 lb
Has written warranty, No
Has written warranty
No
Similar items you might like
Based on what customers bought
Adjustable Infinite Cycle Timer Delay Switch Relay Module 10A 250VAC for Equipment Burn-in, 2.75 x 0.78 Inches / 7 x 2 cm (DC 5V, 0-15 Min) $8.94
5 optionsAvailable in additional 5 options$894current price $8.94Adjustable Infinite Cycle Timer Delay Switch Relay Module 10A 250VAC for Equipment Burn-in, 2.75 x 0.78 Inches / 7 x 2 cm (DC 5V, 0-15 Min)
DC12V 4-Digit LCD Time Relay Switch for Cyclic On/Off Control, 20A 240W, 99:59 Timing $12.98
$1298current price $12.98DC12V 4-Digit LCD Time Relay Switch for Cyclic On/Off Control, 20A 240W, 99:59 Timing
2X DC 12V 1 Channel Relay Module FRM01 Multifunction Relay Loop Delay Timer Switch Self-Locking Timing Board $13.15
$1315current price $13.152X DC 12V 1 Channel Relay Module FRM01 Multifunction Relay Loop Delay Timer Switch Self-Locking Timing Board
Novixy Digital Cycle Timer Delay Relay, 18 Modes Programmable Time Switch with LED Display, AC 110-220V 20A for Automation Lighting Control $10.87
$1087current price $10.87Novixy Digital Cycle Timer Delay Relay, 18 Modes Programmable Time Switch with LED Display, AC 110-220V 20A for Automation Lighting Control
12V Time Relay Module Adjustable Timer Switch Board for Alarm Control 10s-3000s Trigger Delay $9.45
$945current price $9.4512V Time Relay Module Adjustable Timer Switch Board for Alarm Control 10s-3000s Trigger Delay
DC 12V Adjustable Timer Delay Turn OFF Module Timing Relay Time Switch 1~10sec, Delay Off Switch Module, Timer Relay Module $8.25
$825current price $8.25DC 12V Adjustable Timer Delay Turn OFF Module Timing Relay Time Switch 1~10sec, Delay Off Switch Module, Timer Relay Module
Rollback, DC 12V Adjustable Timer Delay Turn OFF Module Timing Relay Time Switch 1~10sec $8.61 Was $14.45
Rollback
$861current price $8.61, Was $14.45$14.45DC 12V Adjustable Timer Delay Turn OFF Module Timing Relay Time Switch 1~10sec
Small Size NE555 Delay Timer Module Relays Switching Module For Automotive Appliance $11.13
2 optionsAvailable in additional 2 options$1113current price $11.13Small Size NE555 Delay Timer Module Relays Switching Module For Automotive Appliance
DC 12V Timing Timer Delay 1-10S Time Adjustable Relay with Indicator Light Turn OFF Relay Module Trigger Delay Switch,1 x Module,blue $9.09
$909current price $9.09DC 12V Timing Timer Delay 1-10S Time Adjustable Relay with Indicator Light Turn OFF Relay Module Trigger Delay Switch,1 x Module,blue
Delay Timer Relay Infinite Loop Loop Module ON OFF Module High Quality $8.98 Was $11.27
$898current price $8.98, Was $11.27$11.27Delay Timer Relay Infinite Loop Loop Module ON OFF Module High Quality
Open Timer Control Module 12V 24V 110V-220V Time Delay Module $9.09 Was $10.39
2 optionsAvailable in additional 2 options$909current price $9.09, Was $10.39$10.39Open Timer Control Module 12V 24V 110V-220V Time Delay Module
2X -521 Digital Time Delay 1 Way Relay Trigger Cycle Timer Delay Switch Circuit Board Timing Control Module,2 x Module,Blue $8.99
$899current price $8.992X -521 Digital Time Delay 1 Way Relay Trigger Cycle Timer Delay Switch Circuit Board Timing Control Module,2 x Module,Blue
CN101A Industrial 12V Digital LCD Power Timer, Programmable Time Switch Relay, 1-Channel $10.57
$1057current price $10.57CN101A Industrial 12V Digital LCD Power Timer, Programmable Time Switch Relay, 1-Channel
Dc 12V Normally Open Time Delay Relay Support Microled Display Automation Cycle Delay Timer Control Off Switch Delay Time Relay $6.99
$699current price $6.99Dc 12V Normally Open Time Delay Relay Support Microled Display Automation Cycle Delay Timer Control Off Switch Delay Time Relay
DC 12V 1 Channel Relay Module FRM01 Multifunction Relay Loop Delay Timer Switch Self-Locking Timing Board $9.89
$989current price $9.89DC 12V 1 Channel Relay Module FRM01 Multifunction Relay Loop Delay Timer Switch Self-Locking Timing Board
Rollbacks & More DC 12V 1 Channel Relay Module FRM01 Multifunction Loop Delay Timer Switch Self-Locking Timing Board $10.31
$1031current price $10.31Rollbacks & More DC 12V 1 Channel Relay Module FRM01 Multifunction Loop Delay Timer Switch Self-Locking Timing Board
TeeRees Dc12V Adjustable Infinite Cycle Loop Delay Timer Time Relay Switch on Off Module $7.99
$799current price $7.99TeeRees Dc12V Adjustable Infinite Cycle Loop Delay Timer Time Relay Switch on Off Module
DC 12V 1 Channel Relay Module FRM01 Multifunction Relay Loop Delay Timer Switch Self-Locking Timing Board $9.57
$957current price $9.57DC 12V 1 Channel Relay Module FRM01 Multifunction Relay Loop Delay Timer Switch Self-Locking Timing Board
Clearance, Misright 12V/24V 30A Delay Timer Module Optocouple Module 30A Switching Timer $10.42 Was $11.64
Clearance
$1042current price $10.42, Was $11.64$11.64Misright 12V/24V 30A Delay Timer Module Optocouple Module 30A Switching Timer
TeeRees DC12V Adjustable infinite Cycle Loop Delay Timer Time Relay Switch on off Module $7.99
$799current price $7.99TeeRees DC12V Adjustable infinite Cycle Loop Delay Timer Time Relay Switch on off Module
About this item
Product details
Timer Multifunction Delay Time Module Control Relay Cycle Timer DC 12V
Specification:
This is a delay timer module with high performance, which is convenient and practical for users.
Features:
New upgrades to simplify, meeting the users' needs.
Increase the power supply anti-reverse function.
LED digits display, intelligent control, time relay/delay function.
The use of opto isolated input and output, enhanced anti-jamming capability and consumption.
The last setting parameters can be memorized after power off.
Power saving function, one-key , can turn off the display.
To ensure stability, industrial grade PCB board.
Working modes selection: after power on, press K1 for 2s, later into the selection of modes: P1~3.
P-1: Monostable delay, a to relay, time is up, the relay disconnect;
P-2: A and countdown begins, T1 seconds after, the relay open T2 seconds, then close;
P-3: Open T1 seconds, disconnect T2 seconds, infinite . Users can set the relay time T1 and T2;
Specifications:
Display: LED Digital Display
Voltage: DC 12V
Timing RangeSettable: 0~.9 seconds; 0~9999 seconds; 0~9999 minutes
Relay Specification: DC 5~30V 10A or AC 220V 10A
Static Current: 20mA
Working Current: 50mA
Working Temperature: -40-85°C
PCB Size: 65 x 38 x 18mm / 2.56 x 1.5 x 0.7in L x W x H
PCB Weight: 26g / 0.93oz
Package Size: 11.5 x 7.5 x 2cm / 4.53 x 2.95 x 0.8in L x W x H
Package List:
1 x Delay Timer Module
Package List:
1 x Delay Timer Module
Specification:
This is a delay timer module with high performance, which is convenient and practical for users.
Features:
New upgrades to simplify, meeting the users' needs.
Increase the power supply anti-reverse function.
LED digits display, intelligent control, time relay/delay function.
The use of opto isolated input and output, enhanced anti-jamming capability and consumption.
The last setting parameters can be memorized after power off.
Power saving function, one-key , can turn off the display.
To ensure stability, industrial grade PCB board.
Working modes selection: after power on, press K1 for 2s, later into the selection of modes: P1~3.
P-1: Monostable delay, a to relay, time is up, the relay disconnect;
P-2: A and countdown begins, T1 seconds after, the relay open T2 seconds, then close;
P-3: Open T1 seconds, disconnect T2 seconds, infinite . Users can set the relay time T1 and T2;
Specifications:
Display: LED Digital Display
Voltage: DC 12V
Timing RangeSettable: 0~.9 seconds; 0~9999 seconds; 0~9999 minutes
Relay Specification: DC 5~30V 10A or AC 220V 10A
Static Current: 20mA
Working Current: 50mA
Working Temperature: -40-85°C
PCB Size: 65 x 38 x 18mm / 2.56 x 1.5 x 0.7in L x W x H
PCB Weight: 26g / 0.93oz
Package Size: 11.5 x 7.5 x 2cm / 4.53 x 2.95 x 0.8in L x W x H
Package List:
1 x Delay Timer Module
Package List:
1 x Delay Timer Module
