Silverstone Platinum FX SST-FX0600FCPT-A 600W Power Supply (fx600-pt)

(No ratings yet)

Key item features

  • Compact Form: Supports the standard Flex ATX form factor, measuring 81.5mm (W) x 40.5mm (H) x 150mm (D), making it suitable for space-constrained builds.
  • Robust Power: Delivers a continuous 600W output at 40°C, rated for 24/7 operation, with a high power density of 1212W per liter.
  • Efficient Performance: Achieves 89% to 91% overall efficiency with Active PFC (PF>0.9 at full load) and a combined +12V output of 600W.
  • Comprehensive Protection: Features multiple safeguards including over current, over power, over voltage, short circuit, under voltage, and over temperature protection.
  • Versatile Connectivity: Includes a 24/20-Pin motherboard connector, 8/4-Pin EPS/ATX 12V, 8-Pin EPS, two 8/6-Pin PCIe, four SATA, three 4-Pin Peripheral, and one 4-Pin Floppy connector.
  • Quiet Cooling: Equipped with a single 40mm silent fan that intelligently adjusts speed based on loading conditions, maintaining a noise level between 20dBA and 48dBA.
  • Reliable Components: Utilizes a class-leading single +12V rail with a Japanese primary capacitor, contributing to an MTBF of 100,000 hours.
Generated by AI

Specs

Computer power supply form factor, Flex ATXBrand, SilverStone TechnologyInput voltage, 120 VInternal/external, InternalSize, 1.6" x 3.2" x 5.9"Has nrtl listing certification, N

About this item

Product details

Product No. SST-FX600-PT
Max. DC Output: 600W
Power density: 1212W per liter
Model (safety certification): SST-FX0600FCPT-A
Combined +3.3V & +5V: 80W
Combined +12V: 600W
Input Voltage: 90 ~ 264 Vrms
Input Frequency Range: 47Hz ~ 63Hz
PFC: Active PFC (PF>0.9 at full load)
Efficiency: =89% & <91% overall efficiency
MTBF: 100,000 hours
Operating temperature: 0°C ~ 40°C
Protection:
Over current protection
Over power protection
Over voltage protection
Short circuit protection
Under voltage protection
Over temperature protection
Connectors:
1 x 24 / 20-Pin motherboard connector
1 x 8 / 4-Pin EPS / ATX 12V connector
1 x 8-Pin EPS connector
2 x 8 / 6-Pin PCIe connectors
4 x SATA connectors
3 x 4-Pin Peripheral connectors
1 x 4-Pin Floppy connector
Cooling System:Single 40mm silent fan
Form factor:Flex ATX
Noise Level: 20 dBA minimum
Dimension:
81.5mm (W) x 40.5mm (H) x 150mm (D)
3.21" (W) x 1.59" (H) x 5.91" (D)
Weight: 1.12 kg
Certification: Cybenetics Platinum

  • Support standard Flex ATX form factor
  • 600W continuous power output at 40℃ operating temperature rated for 24/7 operation
  • Class-leading single +12V rail with Japanese primary capacitor
  • PCIe 8pin and PCIe 6pin connectors support
  • Intelligent built-in fan adjusts speed based on loading conditions (20dBA ~ 48dBA)
info:
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here, and we have not verified it.

Specifications

Computer power supply form factor

Flex ATX

Brand

SilverStone Technology

Input voltage

120 V

Internal/external

Internal

Warranty

Warranty information

3 Year
