Renogy 10A Solar In-Line Fuse Holder Waterproof w/ Fuse

Renogy 10A Solar In-Line Fuse Holder Waterproof w/ Fuse Renogy 10A Solar In Line Fuse Holder Waterproof w Fuse Renogy 15A Male and Female Solar In Line Fuse Holder Waterproof w Fuse Renogy RNGCNCTFUSE20G1US Waterproof Solar Inline Fuse Holder 20A Renogy 30A Male and Female Solar In Line Fuse Holder Waterproof w Fuse

Size10 Amp

Key item features

About this item

Ease of Use

Compatible with PV cables with different insulation diameters.

Designed for a wide range of DC applications.

Simple plug-and-play.

Auto-lock equipment of male and female points render connections easy and reliable.

Safe

Waterproof - IP67 Class Protection.

Insulation material PPO.

High current-carrying capacity

Protection Class II

Connector adopts touch and insertion of reed with inner-knob type
Specifications

Nominal Voltage: 12.8V

Rated Current: 10A

Degree of Protection: IP2*/IP67

Rated Voltage: 1000 V

DC Flame Class: UL94-V0

Test Voltage: 6000V (50Hz,1 min)

Safety Class: II

Overvoltage Category: CATIII

Suitable Connector: Solar Connector

Contact Resistance of Plug Connector:1mΩ

Insertion Force / Withdrawal Force: ≤50N / ≥50N

Contact Material: Copper, Silver Plated

Fuse Can Replace

Insulation Material: PPO

Temperature Range: -40 to +125°C
Warranty

1-year material warranty

Specs

Amps, 10 AElectrical fuse type, DC FusesVolts, 1000 VoltsBrand, RenogyFire safety certifications, UL94-V0Manufacturer, Renogy

Reviews summary

About this item

Product details

This product is a 10A fuse embedded into a waterproof fuse holder. It features an MC4 connector lead on each end, making it compatible for use with an Adaptor Kit and solar panel leads. This Fuse Holder is designed to provide complete single circuit protection to your solar power array. The fuses prevent large currents from damaging the solar panels. Purchase this product for extra protection on your system.

About this item

Ease of Use

Compatible with PV cables with different insulation diameters.

Designed for a wide range of DC applications.

Simple plug-and-play.

Auto-lock equipment of male and female points render connections easy and reliable.

Safe

Waterproof - IP67 Class Protection.

Insulation material PPO.

High current-carrying capacity

Protection Class II

Connector adopts touch and insertion of reed with inner-knob type
Specifications

Nominal Voltage: 12.8V

Rated Current: 10A

Degree of Protection: IP2*/IP67

Rated Voltage: 1000 V

DC Flame Class: UL94-V0

Test Voltage: 6000V (50Hz,1 min)

Safety Class: II

Overvoltage Category: CATIII

Suitable Connector: Solar Connector

Contact Resistance of Plug Connector:1mΩ

Insertion Force / Withdrawal Force: ≤50N / ≥50N

Contact Material: Copper, Silver Plated

Fuse Can Replace

Insulation Material: PPO

Temperature Range: -40 to +125°C
Warranty

1-year material warranty
