100% brand new and high quality
Features：
RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom.
Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz.
264KB of SRAM, and 2MB of on-board Flash memory.
USB-C connector, keeps it up to date, easier to use.
Castellated module allows soldering direct to carrier boards.
USB 1.1 with device and host support.
Low-power sleep and dormant modes.
Drag-and-drop programming using mass storage over USB.
29 × multi-function GPIO pins (20× via edge pinout, others via solder points).
2 × SPI, 2 × I2C, 2 × UART, 4 × 12-bit ADC, 16 × controllable PWM channels.
Accurate clock and timer on-chip.
Temperature sensor.
Accelerated floating-point libraries on-chip.
8 × Programmable I/O (PIO) state machines for custom peripheral support.
Specifications：
Type: RP2040-Zero , Zero M(optional)
USB Type-C connector
W25Q16JVUXIQ
2MB NOR-Flash
BOOT button：press it when resetting to enter download mode
RESET button
WS2812：cool RGB LED
ME621：low dropout LDO, max current 800MA
RP2040：dual-core processor, up to 133MHz operating frequency
RP2040 pins：10x solder points, 9 of which are for GPIO
Note：
Please allow 1-3mm error due to manual measurement. pls make sure you do not mind before you bid.
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
Package Includes：
1PC x RP2040 Chip
