Asus ROG Strix 1200W Power Supply - Internal - 120 V AC, 230 V AC Input - 3.3 V DC, 5 V DC, 12 V DC, -12 V DC, 5 V SB Output - 1200 W - Active PFC - 1 +12V Rails - PCI Express Connector - 1 Fan(s) ...

Technical Information

Specification Compliance: ATX12V, ATX 3.1
Efficiency: 92%
Power Factor Correction (PFC): Active
Number of Fans: 1
Fan Bearing Type: Dual Ball Fan Bearing
Protection Type: Over Power, Over Voltage, Under Voltage, Short Circuit, Over Current, Over Temperature
Modular: Yes

Reliability

MTBF: 120000 Hour

Power Description

Number of +12V Rails: 1
Input Voltage: 120 V AC, 230 V AC
Output Voltage: 3.3 V DC, 5 V DC, 12 V DC, -12 V DC, 5 V SB
Output Voltage Detail: 3.3 V DC @ 25 A, 5 V DC @ 25 A, -12 V DC @ 0.3 A, 5 V DC @ 3 A, 12 V DC @ 100 A
Output Power: 1200 W

Interfaces/Ports

Number of SATA Power Connectors: 6
PCI Express Connector: Yes
Number of (6+2 pin) PCI Express Power Connectors: 4
Number of (4+4 pin) CPU Power Connectors: 2

Environmental Conditions

Minimum Operating Temperature: 77°F (25°C)
Maximum Operating Temperature: 122°F (50°C)

Physical Characteristics

Form Factor: Internal
Height: 6.3"
Width: 5.9"
Depth: 3.4"
Weight (Approximate): 6.48 lb
