Spring Tensile Compression Testing Machine Spring Tester
(No ratings yet)
Key item features
- English LCD, high precision resolution.
- There are N, KG, LB three kinds of measurement units to choose from.
- Can store 99 groups of test data, can view data on the machine and delete data.
- Real-time, peak and automatic peak modes can be switched at will.
- Using Modbus - RTU standard protocol, using USB interface to better connect with configuration PLC.
Specs
Brand, Techtongda
Measurement accuracy, 1%
Features, Precision
Power type, Corded Electric
Display, LCD
Compatibility, PLC via USB Interface
Brand
Techtongda
Measurement accuracy, 1%
Measurement accuracy
1%
Features, Precision
Features
Precision
Power type, Corded Electric
Power type
Corded Electric
Display, LCD
Display
LCD
Compatibility, PLC via USB Interface
Compatibility
PLC via USB Interface
Similar items you might like
Based on what customers bought
Stainless Steel Angle of Repose Tester Powder Particle Repose Angle Measuring Instrument $759.00
$75900current price $759.00Stainless Steel Angle of Repose Tester Powder Particle Repose Angle Measuring Instrument
Stainless Steel Powder Repose Angle Tester Dust Repose Angle Tester $599.00
$59900current price $599.00Stainless Steel Powder Repose Angle Tester Dust Repose Angle Tester
Impact Testing Machine Aggregate Impact Value (AIV) Drop Penetration Tester with Counter $639.00
$63900current price $639.00Impact Testing Machine Aggregate Impact Value (AIV) Drop Penetration Tester with Counter
Defelsko Pin Hole Detector,Test Volt 9, 67.5, 90V PosiTest LPD Basic Kit $659.42
$65942current price $659.42Defelsko Pin Hole Detector,Test Volt 9, 67.5, 90V PosiTest LPD Basic Kit
Triplett Static Sensor SFM500 $660.57
$66057current price $660.57Triplett Static Sensor SFM500
Sensor,5 in H,Plastic 605202 $300.20
$30020current price $300.20Sensor,5 in H,Plastic 605202
Spring Impact Hammer Spring Impact Tester Shielding Mechanical Impact Testing Spring Impactor 0.14J $129.00 Was $189.00
$12900current price $129.00, Was $189.00$189.00Spring Impact Hammer Spring Impact Tester Shielding Mechanical Impact Testing Spring Impactor 0.14J
ETH-500 Spring Tensile Compression Testing Machine Spring Pull Pressure Testing Machine with Printing $748.00
$74800current price $748.00ETH-500 Spring Tensile Compression Testing Machine Spring Pull Pressure Testing Machine with Printing
Techtongda Copper Wire Elongation Tester Wire Tension Stretch Tester 0.03-3.2mm $999.00
$99900current price $999.00Techtongda Copper Wire Elongation Tester Wire Tension Stretch Tester 0.03-3.2mm
ACE-1 Manual Precision Concentricity Measuring Instrument Bearing Gear Coaxiality Tester $759.00
$75900current price $759.00ACE-1 Manual Precision Concentricity Measuring Instrument Bearing Gear Coaxiality Tester
Printing Ink Abraser Friction Testing Machine Decoloration Tester Commercial 110V 60HZ 50W $739.00
$73900current price $739.00Printing Ink Abraser Friction Testing Machine Decoloration Tester Commercial 110V 60HZ 50W
Analyzer,N2,3-3/4" H x 3" Wx1-11/32" D R217P67 $731.55
$73155current price $731.55Analyzer,N2,3-3/4" H x 3" Wx1-11/32" D R217P67
EQCOTWEA CS-2 Friability Analysing Tester Tablet Friability Apparatus Brittleness Test Counter Plastic $739.00 Was $779.00
$73900current price $739.00, Was $779.00$779.00EQCOTWEA CS-2 Friability Analysing Tester Tablet Friability Apparatus Brittleness Test Counter Plastic
Velocity Matrix Probe,25 to 8000 FPM 801090 $514.03
$51403current price $514.03Velocity Matrix Probe,25 to 8000 FPM 801090
Sper Scientific Torque Meter $864.30
$86430current price $864.30Sper Scientific Torque Meter
Paper Tear Tester Film Packaging Material Tear Strength Tester Drop Hammer Type $1,299.00
$1,29900current price $1,299.00Paper Tear Tester Film Packaging Material Tear Strength Tester Drop Hammer Type
Renishaw M-2253-0954 CMM Calibration Test Bar: CAT 40 Use with All Machines $572.25
$57225current price $572.25Renishaw M-2253-0954 CMM Calibration Test Bar: CAT 40 Use with All Machines
Kern FK-A02 Tensiometer Kit for High Capacity Tensile Strength Testing Up to 1000 $616.73
$61673current price $616.73Kern FK-A02 Tensiometer Kit for High Capacity Tensile Strength Testing Up to 1000
UEI Test Instruments HET Heat Exchanger Tester $546.90
$54690current price $546.90UEI Test Instruments HET Heat Exchanger Tester
Mitutoyo Dial Indicator,0 to 3 In,0-100 4887A-19 $643.39
$64339current price $643.39Mitutoyo Dial Indicator,0 to 3 In,0-100 4887A-19
About this item
Product details
Product Overview:
With printing spring pull pressure testing machine is a special instrument for testing the deformation and load relationship characteristics of tensile and compression spring. The printing spring pull pressure testing machine is suitable for tensile and compression spring under a certain working length of the workload test, can also be used for rubber and other elastic components of the elastic load test.This type with printing spring pull pressure testing machine using advanced high integration of integrated microcontroller and Chinese liquid crystal display, the appearance of the metal shell, greatly improve the anti-interference ability of the system.
Product Parameters:
Model: ETH- 500
Power Supply: AC110-220V 50HZ/60HZ
Maximum testing load: 500N/50kg(110.2lbs)
Minimum resolution: 0.01N
Diameter of the platen: 1.9"(48mm)
Maximum free length of measurable spring: 5.9"(150mm)
Length of travel of the displacement scale: 3.5"(90mm)
Division value of the displacement scale: 0.01mm
Indication error: ±1%
Power capability (without printer): 13W
Power capability (with printer): 20W
Working temperature: 20±10℃
Temperature of storage and transportation: -27℃~+70℃
Relative temperature: 15%~80%RH
Product size: 8.7"*11.8"*22.8"(22*30*58cm)
Gross weight: 52.9lb(24kg)
Item Included(056251):
Techtongda Spring pull pressure testing machine
USB cable * 1
The power cord * 1
Wrench * 2
English instruction manual *1
With printing spring pull pressure testing machine is a special instrument for testing the deformation and load relationship characteristics of tensile and compression spring. The printing spring pull pressure testing machine is suitable for tensile and compression spring under a certain working length of the workload test, can also be used for rubber and other elastic components of the elastic load test.This type with printing spring pull pressure testing machine using advanced high integration of integrated microcontroller and Chinese liquid crystal display, the appearance of the metal shell, greatly improve the anti-interference ability of the system.
Product Parameters:
Model: ETH- 500
Power Supply: AC110-220V 50HZ/60HZ
Maximum testing load: 500N/50kg(110.2lbs)
Minimum resolution: 0.01N
Diameter of the platen: 1.9"(48mm)
Maximum free length of measurable spring: 5.9"(150mm)
Length of travel of the displacement scale: 3.5"(90mm)
Division value of the displacement scale: 0.01mm
Indication error: ±1%
Power capability (without printer): 13W
Power capability (with printer): 20W
Working temperature: 20±10℃
Temperature of storage and transportation: -27℃~+70℃
Relative temperature: 15%~80%RH
Product size: 8.7"*11.8"*22.8"(22*30*58cm)
Gross weight: 52.9lb(24kg)
Item Included(056251):
Techtongda Spring pull pressure testing machine
USB cable * 1
The power cord * 1
Wrench * 2
English instruction manual *1
- English LCD, high precision resolution.
- There are N, KG, LB three kinds of measurement units to choose from.
- Can store 99 groups of test data, can view data on the machine and delete data.
- Real-time, peak and automatic peak modes can be switched at will.
- Using Modbus - RTU standard protocol, using USB interface to better connect with configuration PLC.
