Spring Tensile Compression Testing Machine Spring Tensile Tester with Printing

(No ratings yet)

Key item features

‌English LCD, high precision resolution.
There are N, KG, LB three kinds of measurement units to choose from.
Can store 99 groups of test data, can view data on the machine and delete data.
Real-time, peak and automatic peak modes can be switched at will.
Using Modbus - RTU standard protocol, using USB interface to better connect with configuration PLC.

Specs

Brand
Preasion
Features
Electronic Display
Housing material
Metal
Height
22.8 in
Weight
52.9 lb
Model
ETH- 500

Current price is $721.92

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives between Jun 30 - Jul 2

Sold and shipped by Sunflower'yaxun Co.Ltd

4.032258064516129 stars out of 5, based on 93 seller reviews(4.0)

Free 30-day returns

About this item

Product details

Product Overview:
With printing spring pull pressure testing machine is a special instrument for testing the deformation and load relationship characteristics of tensile and compression spring. The printing spring pull pressure testing machine is suitable for tensile and compression spring under a certain working length of the workload test, can also be used for rubber and other elastic components of the elastic load test.This type with printing spring pull pressure testing machine using advanced high integration of integrated microcontroller and Chinese liquid crystal display, the appearance of the metal shell, greatly improve the anti-interference ability of the system.

Product Parameters:
Model: ETH- 500
Power Supply: AC110-220V 50HZ/60HZ
Maximum testing load: 500N/50kg(110.2lbs)
Minimum resolution: 0.01N
Diameter of the platen: 1.9"（48mm）
Maximum free length of measurable spring: 5.9"（150mm）
Length of travel of the displacement scale: 3.5"（90mm）
Division value of the displacement scale: 0.01mm
Indication error: ±1%
Power capability (without printer): 13W
Power capability (with printer): 20W
Working temperature: 20±10℃
Temperature of storage and transportation: -27℃～+70℃
Relative temperature: 15%～80%RH
Product size: 8.7"*11.8"*22.8"（22*30*58cm）
Gross weight: 52.9lb（24kg）

Item Included(056251):
Spring pull pressure testing machine *1
USB cable * 1
The power cord * 1
Wrench * 2
English instruction manual *1

‌English LCD, high precision resolution.
There are N, KG, LB three kinds of measurement units to choose from.
Can store 99 groups of test data, can view data on the machine and delete data.
Real-time, peak and automatic peak modes can be switched at will.
Using Modbus - RTU standard protocol, using USB interface to better connect with configuration PLC.
