Rotary Encoder / Rotation Sensor Module with Pushbutton Switch for Arduino AVR PIC DIY KY-040
Rotary Encoder / Rotation Sensor Module with Pushbutton Switch for Arduino AVR PIC DIY KY-040
Hero image 0 of Rotary Encoder / Rotation Sensor Module with Pushbutton Switch for Arduino AVR PIC DIY KY-040, 0 of 5

Rotary Encoder / Rotation Sensor Module with Pushbutton Switch for Arduino AVR PIC DIY KY-040

(No ratings yet)

Key item features

  • Continuous 360-Degree Rotation: Spins freely in both directions with no mechanical stops, providing unlimited rotational input for menu navigation, volume controls, and parameter adjustment.
  • 20 Detents Per Revolution: Each click represents an 18-degree step with tactile feedback, giving precise step-by-step control for accurate input.
  • Quadrature Output for Direction Detection: Two digital output channels (CLK and DT) let your microcontroller determine both the direction and amount of rotation.
  • Built-in Pushbutton Switch: Press the encoder shaft to activate a normally-open momentary switch (active LOW), adding a second input for confirming selections or toggling modes.
  • On-Board 10K Ohm Pull-Up Resistors: Pull-up resistors on CLK, DT, and SW lines are included on the PCB, so no external resistors or extra components are needed.
  • 5V and 3.3V Compatible: Works with Arduino, Raspberry Pi, ESP32, STM32, Teensy, PIC, AVR, and other common microcontroller platforms.
  • Simple 5-Pin Interface: Connect CLK, DT, SW, power, and ground using standard jumper wires for fast, easy setup.

Specs

Switch encoder type, Rotary EncoderBrand, Envistia MallModel name, KY-040Volts, 5 VDimensions, 2.50 x 1.80 x 2.80 CentimetersHas written warranty, No

About this item

Product details

KY-040 Rotary Encoder Module with Pushbutton Switch

The KY-040 Rotary Encoder Module is a continuous 360-degree rotary input device with a built-in pushbutton switch. It outputs digital quadrature signals that let your microcontroller detect both the direction and amount of rotation. On-board 10K ohm pull-up resistors on all signal lines mean you can connect directly to an Arduino or other microcontroller with just jumper wires.

How It Works

  1. Connect the module's five pins (CLK, DT, SW, +, GND) to your microcontroller using jumper wires.
  2. As you turn the knob, two internal switches produce offset digital pulses on the CLK and DT pins.
  3. Your code compares the CLK and DT signals to determine which direction the knob is turning and how many steps it has moved.
  4. Press down on the encoder shaft to activate the built-in pushbutton switch, which pulls the SW pin LOW.

Specifications

  • Model: KY-040
  • Encoder Type: Incremental rotary encoder
  • Operating Voltage: 5V DC (also works with 3.3V)
  • Detents Per Revolution: 20 (18 degrees per detent)
  • Pulses Per Revolution: 20
  • Rotation: Continuous 360 degrees (no mechanical stops)
  • Pushbutton Switch: Normally open, momentary (active LOW)
  • On-Board Pull-Up Resistors: 10K ohm on CLK, DT, and SW
  • Output Signal: 2-bit quadrature (Gray code)
  • Module Dimensions: Approx. 30 x 18 x 30 mm (1.18 x 0.71 x 1.18 inches) L x W x H

What's in the Box

  • 1x KY-040 Rotary Encoder Module (with knob shaft)

Jumper wires, microcontroller board, and knob cap are not included. Any standard 6mm D-shaft knob will fit.

Compatible With

  • Arduino (Uno, Mega, Nano, Leonardo, Due, and compatibles)
  • Raspberry Pi (all models)
  • ESP32 and ESP8266
  • STM32, Teensy, PIC, and AVR microcontrollers

Typical Applications

  • Menu navigation and selection on LCD or OLED displays
  • Volume and brightness controls
  • Parameter adjustment (set points, thresholds, timer values)
  • Stepper and servo motor speed and direction control
  • CNC and 3D printer manual jog controls
  • DIY audio equipment (amplifiers, mixers)
  • Robotics steering and configuration input

Important Notes

  • Mechanical encoders produce contact bounce. Use software debouncing or add 100nF capacitors between CLK/GND and DT/GND for clean signals.
  • For best responsiveness, connect CLK and DT to interrupt-capable pins (Pins 2 and 3 on Arduino Uno).
  • Keep jumper wires under 20cm (8 inches) to minimize electrical noise.
  • Continuous 360-Degree Rotation: Spins freely in both directions with no mechanical stops, providing unlimited rotational input for menu navigation, volume controls, and parameter adjustment.
  • 20 Detents Per Revolution: Each click represents an 18-degree step with tactile feedback, giving precise step-by-step control for accurate input.
  • Quadrature Output for Direction Detection: Two digital output channels (CLK and DT) let your microcontroller determine both the direction and amount of rotation.
  • Built-in Pushbutton Switch: Press the encoder shaft to activate a normally-open momentary switch (active LOW), adding a second input for confirming selections or toggling modes.
  • On-Board 10K Ohm Pull-Up Resistors: Pull-up resistors on CLK, DT, and SW lines are included on the PCB, so no external resistors or extra components are needed.
  • 5V and 3.3V Compatible: Works with Arduino, Raspberry Pi, ESP32, STM32, Teensy, PIC, AVR, and other common microcontroller platforms.
  • Simple 5-Pin Interface: Connect CLK, DT, SW, power, and ground using standard jumper wires for fast, easy setup.
