Hero image 0 of R502S Fingerprint Module Fingerprint Recognition Module Capacitive Fingerprint Module Sensor Scanner RGB Ring Indicator, 0 of 8
R502S Fingerprint Module Fingerprint Recognition Module Capacitive Fingerprint Module Sensor Scanner RGB Ring Indicator
(No ratings yet)
Key item features
- Seven-color lights, freely set
- Multiple communication interfaces to meet more application needs
- 150 fingerprints
- Image pixels are 160 x 160
- Quick identification, accurate comparison
Specs
- BrandUnbranded
- Model nameR502S
- Has written warrantyNo
- Piece count150
Current price is USD$16.99
Price when purchased online
- Free shipping
Free 30-day returns
Walmart Protection Plan by Allstate
(Only one option can be selected at a time)
How do you want your item?
Ships to
Arrives between Jul 11 - Jul 16
|Sold and shipped by HER Tools
3.9397590361445785 stars out of 5, based on 83 seller reviews(3.9)83 seller reviews
Free 30-day returns
About this item
Product details
Working voltage: DC 3.3V
Standby current (finger detection): Typical touch standby voltage: 3.3V Average current: 2uA
Working current (fingerprint collection): 20mA
Power-on start time: ≤50ms
Image size: 160 x 160 pixel
Collection area: 15.5mm diameter
Image resolution: 508 dpi
Template size: 2KB
Time to generate feature points: Less than 500 ms
Comparison time: 1:NLess than 10ms/fingerprint
Storage capacity: 150 pieces
False acceptance rate (FAR): ≤0.001%
False rejection rate (FRR): 51%
Working temperature: -20℃ ~+60℃
Storage temperature: -40℃ ~+75℃
Working humidity: 10%~85% (no condensation)
Storage humidity: Less than 85% (no condensation)
Material: Alloy
Color: As shown
Package Contents:
1 x Fingerprint Module
1 x Connection Cable
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
Standby current (finger detection): Typical touch standby voltage: 3.3V Average current: 2uA
Working current (fingerprint collection): 20mA
Power-on start time: ≤50ms
Image size: 160 x 160 pixel
Collection area: 15.5mm diameter
Image resolution: 508 dpi
Template size: 2KB
Time to generate feature points: Less than 500 ms
Comparison time: 1:NLess than 10ms/fingerprint
Storage capacity: 150 pieces
False acceptance rate (FAR): ≤0.001%
False rejection rate (FRR): 51%
Working temperature: -20℃ ~+60℃
Storage temperature: -40℃ ~+75℃
Working humidity: 10%~85% (no condensation)
Storage humidity: Less than 85% (no condensation)
Material: Alloy
Color: As shown
Package Contents:
1 x Fingerprint Module
1 x Connection Cable
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
- Seven-color lights, freely set
- Multiple communication interfaces to meet more application needs
- 150 fingerprints
- Image pixels are 160 x 160
- Quick identification, accurate comparison
