Chengying 24 inch Multi-Touch infrared touch frame IR touch panel Infrared touch overlay, Sizes 15" to 110" - Suitable for Touch monitor, Touch screen, Touch whiteboard

Hero image 0 of Chengying 24 inch Multi-Touch infrared touch frame IR touch panel Infrared touch overlay, Sizes 15" to 110" - Suitable for Touch monitor, Touch screen, Touch whiteboard, 0 of 6

Chengying 24 inch Multi-Touch infrared touch frame IR touch panel Infrared touch overlay, Sizes 15" to 110" - Suitable for Touch monitor, Touch screen, Touch whiteboard

|5 ratings

Size24"

Actual ColorNo display,Touch frame only

No display,Touch frame only

Key item features

Touch Functionality: This infrared touch overlay provides touch input only, without a display, and is designed to be installed in front of an existing monitor or TV screen to enable touch capabilities.
Size Compatibility: The 24-inch model is suitable for monitors ranging from 23" to 24" (display area size <= 24"), with a specific touch area of 307.3mm x 531.5mm.
Technical Specifications: It boasts a resolution of 32768*32768, supports 2K, 4K, and 8K monitors, has a minimum touch object size of 3mm, and a typical response time of 3-10ms.
System Integration: Fully compatible with Windows OS (10-point multi-touch), offers single touch on MacOS, and single or multi-touch on Android and Linux (driver dependent).
Development Support: Protocols include HID, TUIO, and Flash, with a free SDK provided for re-development, supporting languages like C/C++, C#, and Java.
Diverse Applications: Ideal for various uses including education whiteboards, conference machines, vending machines, digital signage, kiosks, exhibitions, and touch TVs.

Generated by AI

Specs

Screen size, 24 inResolution, 32768 x 32768Refresh rate, 200 HzDisplay, No DisplayAspect, 16:9Response time, 3 ms

About this item

Product details

WORKING PRINCIPAL:

Infrared Multi-touch Overlay is not a display, it is a touch pointing device.

Usually installed in front of the display screen.

Navigate the screen with your fingers instead of the mouse.

All you have to do is simply assemble the Multi-touch overlay in front of your existing monitor or TV screen. You will have a new touch screen TV!

Need to be used with a computer, USB connection.

1, Fully compatible with Windows OS,Win8, Win10, Win11, multi-touch supported(10 point touch).

2, On MacOS --- only single touch.

3, On Android, Linux --- single or multi touch (Requires built-in driver to support).

4, For Chrome, Raspberry Pi, or TV built-in OS --- By default, these systems have no touch device driver and no touch function. Please inquiry system supplier if the system be have touch device driver before you order this item.

APPLICATION:

Automatic retail machines, checkout machines, express cabinets, ticket machines, bank terminals, inquiry machines, advertising machines, Interactive touch tables, Conference touch all-in-one machine, Interactive education whiteboard, Digital Signage, Kiosk, Exhibitions, TV Channels, Command Center and Boardroom

X--- No display, Touch function only
X--- Curved displays are not supported
Can work with 23" to 24" (display area size <= 24") monitor
Touch Area Size: 24inch -- 307.3mm X 531.5mm (Please refer to the Product Image for all Dimensions and Drawing)
DurabilityResolution: 32768*32768, support 2k 4k 8k monitors
Minimum Touch Object: 3mm
Typical Response Time: 3-10ms
Protocols: HID,TUIO,Flash. Re-development Provide: free SDK, support C/C++, C#, Java etc.
Certification: FCC,CE,ROHS
Warranty: 1 year
Easy to install, Easy Integration
Application: Education Whiteboard; Conference machine; vending machine; Digital Signage; Kiosk; Exhibitions; Command Center and Boardroom; Touch TV;

info:

We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here, and we have not verified it.

Specifications

Screen size

24 in

Resolution

32768 x 32768

Refresh rate

200 Hz

Display

No Display

Warranty

Warranty information

Warranty period: One year

Please be aware that the warranty terms on items offered for sale by third party Marketplace sellers may differ from those displayed in this section (if any). To confirm warranty terms on an item offered for sale by a third party Marketplace seller, please use the 'Contact seller' feature on the third party Marketplace seller's information page and request the item's warranty terms prior to purchase.
