Simrad NSS9 evo3S and Halo20+ Radar bundleModel: 000-15554-001High Resolution, High Bright, SolarMax IPS DisplaysEasy to use touchscreen UI as well as full keypad for simple and precise control in any sea conditionsBuilt-in advanced echosounder capable of 1kW Dual channel CHIRP, Forwardscan, Sidescan, Downscan and StructureScan 3D imagesTake another step forward with Simrad’s premium network modules for the ultimate offshore performanceHalo Dome and Open Array Radars: S5100 Sportfishing Echosounder, Direct audio, autopilot and engine connection and controlLow profile glass dash stylingBuilt in Wi-Fi connectivityNext Generation ProcessorSolarMAX IPS Display TechnologyMulti-touch screen and keypad hybrid controlBuilt-in Advanced EchosounderNSS evo3S is a mid-life update to the NSS evo3. The key difference is a next generation processor. This greatly improves the speed and smoothness of the display. The NSS evo3 is already a feature packed product and the new processor in the evo3S means that each one of those features is now improvedSpecificationsPhysicalDimensions287 x 166 x 90 mm (11.30 x 6.55 x 3.50")with bracket 311 x 180 x 95 (11.30 x 7.07 x 3.72)Weight1.41kg/3.11lbEnvironmentalOperating temperature range-15°C to +55°C (5° F to 131° F)Environment Shock Vibration100,000 cycles of 20GStorage temperature range-20°C to +60°C (4°F to 140°F)Water resitanceIPX6 and 7PowerSupply voltage10 - 31.2 V DCFuse rating5APower consumption (Max)21WDisplayDisplay backlight colorWhiteDisplay resolution600 x 1280Display screen brightness1200 nitsDisplay size and typeHigh Visibility SolarMax HD® IPS 7" optically bonded TFTDisplay viewing angles80° top/bottom, 80° left/rightConnectivityEthernet1 x 5 pin yellow connector x 1 MbitBluetoothInternalNMEA2000 connectivity1 x NMEA 2000 Micro-C port, 1 LENNMEA 0183 connectivity1 x Transmit, 1 x Receive NMEA 0183, Baud Rates 4800, 9600, 19200, 38400. TX and RX use same baud rate. Optional data cable required (P/N 000-00129-001)Video connectivity2 x composite (RCA connectors)video inputs. Optional video/ data cable required (P/N 000-00129-001).WiFi connectivityInternalSonarSonar frequencies40-250kHz 455-800kHzSonar max depth3000’+ (tested with B175L)Sonar output power1kW RMSComplianceComplianceGPSGPSInternalGPS update rate10 HzGPS channels34GPS correctionWASS, EGNOS, MSAS, GLONASSGPS position accuracyHorizontal Accuracy 3 m (9.8 ft)GPS time to first fixCold start 50 sec, Satellite Reacquisition 5 secWhat's in the Box:HALO20+,SIMRAD,20",RADARScanner cable, 10 m (33 ft)Cable, RJ45 TO 5 PIN,1.5 m (4.9 ft)NSS9 EVO3S COMBONSS9 EVO3 SUN COVERNSS9 EVO3 & ZEUS - 9 Mounting BracketNSS9 EVO3 & ZEUS3 - 9 DASH MOUNT KITNSS9 EVO3 & ZEUS3 — 9 EDGE BEZELSPower Cable
