Boat part number 1076292 is a new diesel fuel filter / water separator from Racor / Parker, part number 500MA30 .The Racor Marine Fuel Filter Water Separator Turbine Series is the most trusted fuel filter water separator on the market. features a 3-stage filtration system that effectively removes water and particulates from fuel, providing maximum protection of diesel engine components in marine applications where reliability is critical. For optimal performance, Turbine Series marine filter assemblies should be installed on the vacuum side of the fuel transfer pump.Utilizes Racor's Aquabloc filtration elements, which is a unique engineered media to increase dirt-holding capacity and extend filter life. Captures contaminants while the specially treated surface separates and coalesces water from the fuel, which causes the water to gather into large droplets that then fall into the clear collection bowl.This is the 30 micron model 98%30 micron - Ideally suited as a pre-filter to protect downstream filters from excessive contamination. Extends the life of on-engine filters.Specifications: Part Manufacturer: Racor / Parker Series: Marine 500 Turbine Part Number: 500MA30 UPC: 706672004130 Filtered Medium: Diesel Fuel / B20 Flow Rate: 60 GPH / 227 LPH Micron Rating: 98% at 30 Micron Material: Powder Coated Aluminum / Stainless Steel Color: White Overall Dimensions: 11" L x 6 1/2" W including mount x 6" H Ports: 2 3/4-16 UNF-2B SAE Male flare Mounts: 2 5/16" W x 1 1/4" L mounting slots Sold as seen in pictures. Customers please note every computer shows colors differently. All measurements are approximate. Hardware and instruction / installation manual not included.
