Johnson Pump Ultima Bilge 1000 Gph 3 By 4" Hose Dura Port UltimaBilge Pumps are the latest addition to the Johnson Pump brand lineup. Integration of the Ultima "field effect" sensing technology into the bilge pump body creates a sleek, reliable and compact unit with integrated switch ready to install and run for years and years of unerring service. Available in 600-800-1000-1250 GPH versions. Voltage 12 V DC. For UltimaBilge 600 GPH-1000 GPH, we have easy-to-install Dura-Port discharge ports to eliminate stress cracking caused by over-tightened hose clamps. These pumps will be delivered including both a straight and a 90 degree smooth elbow Dura-Port. All version are delivered with a removable check valve. The Ultima Bilge pumps may be manually operated via the Johnson Pump bilge control panel. CE-Approved.
- Compact, all-in-one unit
- Integrated Ultima Switch sensing right into the pump body
- No Mercury
- Removable clip on basket design
- Removable impeller cover allows for easy clean out
- 3-wire device can be run in auto or manual override mode
- No tools needed for maintenance
- Extremely energy efficient
- Water-cooled motor for long service intervals
- Pump Body ABS
- Shaft Seal Lip Seal
- Shaft Stainless steel (SS2343)
- Voltage 12 V DC
- Capacity 3 ft (0.9 m) head (13.6 V) 44 lmin - 700 GPH
- Capacity straight (13.6 V) 64 lmin - 1000 GPH
- Amperage 3.2 A
- Fuse Size 5 A
- Connection 34
- Length142 mm - 6
- Width82 mm - 3.2
- Height105 mm - 4.1
- Weight0.66 kg - 23.3 oz
- Gallons Per Hour 1000
- Operation Automatic
- Outlet Size 34
- Power - Max Continuous (Amps) 3.2 amps
- Box Dimensions 4H x 8W x 9L
- Weight 1.4lbs
- Brand: Johnson Pump
- Model Number: 1135-38966
