Fractal Design Case DEFINE XL R2 FT TIT 4/0/(8) USB3.0 TitaniumGY1c18p
Fractal Design Case DEFINE XL R2 FT TIT 4/0/(8) USB3.0 TitaniumGY1c18p
Hero image 0 of Fractal Design Case DEFINE XL R2 FT TIT 4/0/(8) USB3.0 TitaniumGY1c18p, 0 of 7

Fractal Design Case DEFINE XL R2 FT TIT 4/0/(8) USB3.0 TitaniumGY1c18p

|2 ratings

Key item features

Features
  • Industrial high-density sound absorbing material ensures silent operation
  • Patented ModuVent covers form an effective sound seal on unused fan positions and remove easily to install additional cooling
  • Spacious internal layout with 9 expansion slots
  • Thick rubber grommets and 26 mm of space behind the motherboard plate for easy cable routing
  • Water cooling support in front, top, bottom and rear positions
  • Drive cages can be repositioned or removed for increased airflow or the addition of a front radiator up to 240 mm
  • 2 x USB 3.0, 2 x USB 2.0 and 2 x audio ports on top panel
  • 3 x Fractal Design Silent Series R2 140mm hydraulic bearing fans preinstalled
  • 7 x fan positions
  • Easy access removable nylon filters maintain a dust-free interior with up to 2X the airflow of plastic filters
  • New tool-less front fan holder makes switching front fans a breeze
  • Support for new 6TB+ HDD mounting standards
  • Support for enterprise 2.5" drives with 15mm height
  • Blue LED power and disk activity indicator

Specifications
  • Type: Full Tower
  • Color: Black
  • Case Material: Steel
  • With Power Supply: No
  • Power Supply Mounted: Bottom
  • Power Supply: ATX
  • Motherboard Support: XL-ATX / E-ATX / ATX / MicroATX / Mini-ITX
  • Side Panel Window: No
  • LED: No
  • Removable Filter: Front fans, Bottom + PSU
  • External 5.25" Drive Bays: 4
  • Internal 3.5" Drive Bays: 8 x 3.5"/2.5" universal bays
  • Internal 2.5" Drive Bays: 0
  • Expansion Slots: 9
  • Front Ports: 2 x USB 3.0 / 2 x USB 2.0 / Audio

Fan Options
  • Total fan mounts: 7
  • Front: 2 x 120/140 mm (1 x Silent Series R2 140 mm included)
  • Top: 2 x 120/140 mm
  • Bottom: 1 x 120/140 mm (1 x Silent Series R2 140 mm included)
  • Rear: 1 x 120/140 mm (1 x Silent Series R2 140 mm included)

Radiator Options
  • Front: 240/120 mm radiators (requires relocation/removal of HDD cages)
  • Top: 280/240/140/120 mm slim radiators
  • Bottom: 120 mm radiators
  • Rear: 140/120 mm radiators

Dimensions & Weight
  • Max GPU Length: 330 mm in default configuration; 480 mm with top HDD cage removed
  • Max CPU Cooler Height: 170 mm
  • Max PSU Length: 190 mm in default configuration; 345 mm with bottom fan removed
  • Case Dimensions (LxWxH): 22.05" x 9.13" x 22.09" with feet/screws/protrusions
  • Net Weight: 36.20 lbs.

Package Contents
  • Define XL R2 computer case
  • Accessory box
  • User manual

Specs

Computer case type, Full TowerWeight, 0.1Brand, Fractal DesignColor, SilverNumber of drive bays, 6Number of expansion slots, 9

About this item

Product details

The Define XL R2 has sleek and stylish Scandinavian design sensibilities with superb cooling capacity and exceptional expandability. Its intelligent internal layout equipped with Fractal Design?s innovative ModuVent? technology offers unprecedented expandability, modularity and flexibility. The Define XL R2 has a total of 9 expansion slots, 4 ODD bays, and 8 universal HDD/SSD bays across two drive cages that can be repositioned or removed to accomodate complex water cooling systems.
Features
  • Industrial high-density sound absorbing material ensures silent operation
  • Patented ModuVent covers form an effective sound seal on unused fan positions and remove easily to install additional cooling
  • Spacious internal layout with 9 expansion slots
  • Thick rubber grommets and 26 mm of space behind the motherboard plate for easy cable routing
  • Water cooling support in front, top, bottom and rear positions
  • Drive cages can be repositioned or removed for increased airflow or the addition of a front radiator up to 240 mm
  • 2 x USB 3.0, 2 x USB 2.0 and 2 x audio ports on top panel
  • 3 x Fractal Design Silent Series R2 140mm hydraulic bearing fans preinstalled
  • 7 x fan positions
  • Easy access removable nylon filters maintain a dust-free interior with up to 2X the airflow of plastic filters
  • New tool-less front fan holder makes switching front fans a breeze
  • Support for new 6TB+ HDD mounting standards
  • Support for enterprise 2.5" drives with 15mm height
  • Blue LED power and disk activity indicator

Specifications
  • Type: Full Tower
  • Color: Black
  • Case Material: Steel
  • With Power Supply: No
  • Power Supply Mounted: Bottom
  • Power Supply: ATX
  • Motherboard Support: XL-ATX / E-ATX / ATX / MicroATX / Mini-ITX
  • Side Panel Window: No
  • LED: No
  • Removable Filter: Front fans, Bottom + PSU
  • External 5.25" Drive Bays: 4
  • Internal 3.5" Drive Bays: 8 x 3.5"/2.5" universal bays
  • Internal 2.5" Drive Bays: 0
  • Expansion Slots: 9
  • Front Ports: 2 x USB 3.0 / 2 x USB 2.0 / Audio

Fan Options
  • Total fan mounts: 7
  • Front: 2 x 120/140 mm (1 x Silent Series R2 140 mm included)
  • Top: 2 x 120/140 mm
  • Bottom: 1 x 120/140 mm (1 x Silent Series R2 140 mm included)
  • Rear: 1 x 120/140 mm (1 x Silent Series R2 140 mm included)

Radiator Options
  • Front: 240/120 mm radiators (requires relocation/removal of HDD cages)
  • Top: 280/240/140/120 mm slim radiators
  • Bottom: 120 mm radiators
  • Rear: 140/120 mm radiators

Dimensions & Weight
  • Max GPU Length: 330 mm in default configuration; 480 mm with top HDD cage removed
  • Max CPU Cooler Height: 170 mm
  • Max PSU Length: 190 mm in default configuration; 345 mm with bottom fan removed
  • Case Dimensions (LxWxH): 22.05" x 9.13" x 22.09" with feet/screws/protrusions
  • Net Weight: 36.20 lbs.

Package Contents
  • Define XL R2 computer case
  • Accessory box
  • User manual
info:
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here, and we have not verified it.

Specifications

Computer case type

Full Tower

Weight

0.1

Brand

Fractal Design

Color

Silver

Warranty

Warranty information

1 YEAR

Please be aware that the warranty terms on items offered for sale by third party Marketplace sellers may differ from those displayed in this section (if any). To confirm warranty terms on an item offered for sale by a third party Marketplace seller, please use the 'Contact seller' feature on the third party Marketplace seller's information page and request the item's warranty terms prior to purchase.

Warnings

Customer ratings & reviews

5 out of 5 stars
stars
2 ratings2 reviews
Includes global ratings and reviews
How item rating is calculated
Filtered and sorted results would be available on the new 'Customer ratings & reviews' page.
Sort by |

Showing 1-2 of 2 reviews

Mar 24, 2013
Reviewer name: Wildmagic
5 out of 5 stars
5 out of 5 stars review

Verified Purchase

Overall excellent buy for $129

The case is excellent. Plenty of room for my Geforce GTX 680 graphics card and still have the middle Disc drive bay installed (2-3" to spare). It was wide enough for the Nuctua NH-D14 (a very tall air CPU cooler). Also, I was able to route all my cables behind the motherboard to improve air flow and reduce clutter. The walls have acoustical padding to help quite the fan noise. Another big plus is the lint/dust screen under the case and in the front of the case to prevent hair and dust from entering the case by the fans. The case has a fan controller with three states 5v, 7v, and 12v. I used my Asus Motherboard's fan controller instead. However, the 7v state was best to provide cooling and keep the noise to a minimum according to anantech. The front top has (2) 2.0 USB and (2) 3.0 USB ports along with the mic and speaker ports. It was very convenient to rest a 3.0 USB external hard disc drive on top of the Case since it is completely flat. It comes with rubber grommets to reduce noise and vibration when installing SSD or HDD. Cons: It is very heavy but I guess that helps with reducing noise. The doors are very hard to put back on however, you do not need any tools. The motherboard standoffs are not already installed so you have to figure out which holes to use depending on your motherboard size (ATX, etc...)

Helpful?6J5CRGYAVCH123261992
Mar 15, 2013
Reviewer name: JFractal
5 out of 5 stars
5 out of 5 stars review

Verified Purchase

exactly what i wanted

it's big, it's quiet, and it's grrrrrreat!! couldn't ask for much more in a case. just know that this thing is heavy when you try to move it and wide to accomodate large coolers. used to store two towers next to each other under my desk but can't fit another case next to this one (good reason to move my server elsewhere). wish the usb ports were a little more solid but they seem to be holding steady. also, wish the cpu cutout was a bit wider as it slightly covers two screws for backplate remove/install. i need to work on my cable management a bit better but even with leaving it sloppy i was easily able to close the side panel without hassle. would recommend this to anyone building their own pc as this thing is a breeze to work with and keeps things super quiet and super cool. A+ Fractal!!
