2 Peavey RX22N High Frequency Compression Driver RX22HF RX22

Name: 2 Peavey RX22N High Frequency Compression Driver RX22HF RX22
Brand: Peavey
SKU: 3918386525
Price: 399.98 USD
Availability: InStock

(No ratings yet)

Key item features

Specs

Rms power rating
140 W
Peak audio power handling
280 W
Loudspeaker sensitivity
111 dB
Impedance
8 ohm

Current price is $399.98

Price when purchased online

Free shipping
Free 30-day returns

Walmart Protection Plan by Allstate

(Only one option can be selected at a time)

3-Year Plan - $36.00

4-Year Plan - $49.00

How do you want your item?

Ships to

Arrives by Fri, Jun 12

Sold and shipped by Cyber Overstock Inc.

3.610738255033557 stars out of 5, based on 149 seller reviews(3.6)

Report an issue with this seller

Free 30-day returns

More seller options (1)

Starting from $399.98

About this item

Product details

2 Peavey RX22N High-Frequency Compression Horn Driver RX22HF RX22

This is a direct replacement from Peavey themselves. Let us know if you want more pictures or information about this item. We deal directly with peavey, so let us know if you need more parts for your Peavey equipment. We carry Crossovers, full speakers, and all accessories!

General Features:

2" edge wound voice coil with ferrofluid cooling improves power handling
Screw on 1-3/8" 18 TPI mount is compatible with most popular horns
Throat Parameter: .875" / 22 mm
Nominal Impedance: 8 Ohms
Minimum Impedance: 5.1 Ohms
DC Resistance: 4.7 Ohms
Power Capacity 1000 Hz to 20,000 Hz: 280 W peak 140 W program 70 W continuous using pink noise band-limited from 1000 Hz to 20 kHz(AES 2-1984)
Power Capacity 500 Hz to 20,000 Hz: 240 W peak 120 W program 60 W continuous using pink noise band-limited from 500 Hz to 20 kHz
Sensitivity: 111 dB / 1 Watt at 1 meter On-axis on 90º H x 45º V horn
Nominal Efficiency: 30%
Frequency Response: 500 Hz to 20,000 Hz
Recommended Crossover: 1200 Hz at 12 dB / Octave
Lowest Recommended Crossover: 500 Hz at 12 dB / Octave
Diaphragm: Commercially pure titanium
Voice Coil Diameter: 2.0" / 50.8 mm
Voice Coil Material: Edge-wound copper-clad aluminum ribbon with a high temp composite bobbin
Flux Density: 17,500 gausses (1.75T)
Dimensions: 5.250" (133.3 mm) diameter x 3.05" (77.4 mm) depth
Horn Coupling Diameter: 7/8: (22.2 mm)
Horn Coupling Threads: Standard 1 3/8" / 18"
Net Weight: 5 lbs. 6 oz.
Shipping Weight: 6 lbs. 5.5 oz.
Voice Coil Cooling: Ferrofluid
Weight Unpacked: 5.50 lb(2.493 kg)
Weight Packed: 6.48 lb(2.938 kg)
Width Packed: 8.25"(20.955 cm)
Height Packed: 8.25"(20.955 cm)
Depth Packed: 4.75"(12.065 cm)
