Blue Sea 7040 187 - Series Thermal Circuit Breaker - 60Amp [7040]

(No ratings yet)

Key item features

187 - Series Thermal Circuit Breakers - Panel Mount60 Amp Circuit BreakerPN: 7040Features:
Combines switching and circuit protection into a single device
All components meet SAE J1171 external ignition protection requirements
Clear, single lever operation
"Trip Free" design cannot be held "ON" during fault current condition
Waterproof
Recessed mounting holes for clean appearance
Self-trimming case eliminates the need for mounting panels or trim bezels
Round case permits easy installation with standard sized hole saw
Large clearance around terminal studs accept heavy gauge wire lugs
Robust 5/16 terminals provide high torque connections
Large lever with vertical/horizontal orientation provides indication of trip status
Ignition protected - safe for installation aboard gasoline powered boats Specifications Circuit Breaker Class:Type III - Switchable / Manual Reset - Trip FreeType:Thermally Responsive Bi-Metal BladeCase Material:Thermoset PolyesterVoltage Rating:48 Volts DC MaximumInterrupt Rating:5,000 Amperes @12 Volts DC 3,000 Amperes @24 Volts DC 1,500 Amperes @42 Volts DCOperating Temperature Range:-25C° to +82C°WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:
Amperage: 60a
Box Dimensions: 2"H x 5"W x 8"L WT: 0.5 lbs
UPC: 632085070403
