Simrad VHF Marine Radio, Rs20s, Basic, Gps, N2k (00-14491-001)

(No ratings yet)

Key item features

NMEA 2000 = Yes
Built-In GPS = Yes
AIS = No
Scrambler Capable = No
Remote Mic Capable = No
Hailer = No
Color = Black

Specs

Frequency band type
VHF
Features
Built-In Antenna
Watts
23 Watts
Brand
Simrad
Channels
16
Power type
Battery

Current price is $423.00

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives by Thu, Jun 11

Sold and shipped by ProAnglersChoice

4.4 stars out of 5, based on 15 seller reviews(4.4)

Report an issue with this seller

Free 30-day returns

More seller options (1)

Starting from $423.00

About this item

Product details

Simrad RS20S VHF With DSC

Model: 00014491001

Built in GPS Antenna
Receive GPS data from a compatible GPS unit: SMA connector for optional external GPS antenna (000-13613-001)
Replaces the current RS12 entry level VHF
NMEA2000 connectivity for advanced functionality like backlight grouping when connected to Simrad MFD’s
NMEA0183 connectivity
NMEA0183 connectivity
New front mountable mechanical design for easy installation
Low profile design to align with style of Simrad MFD’s
Full inbuilt country specific channel banks
no requirement for LC programming or cloning

Specifications

Frequency Range: Transmit	156.025?157.425 MHz
Frequency Range: Receive	156.050?163.275 MHz
Number Of Channels	US / INT
Oscillate Mode	PLL
Modulation	FM(16KOG3E) DSC(16K0G2B)
Channel Spacing	25KHz
Frequency Stability	±5 PPM
Normal Working Voltage	+13.6 V DC
Minimum operating Voltage	≥10 V DC
Low battery detect Voltage	10.5 ± 0.5 V DC
Digital Selectivity Calling (DSC)	Class D
Intermediate Frequency : 1st	38.85/21.7 MHz
Intermediate Frequency : 2nd	450 KHz
Sensitivity : 12dB SINAD	≥-6 dBuV(EMF)
Squelch Sensitivity: at tight	≤ 6 dBuV(EMF)
Adjacent Channel Selectivity	≤70 dB
Intermodulation Response	≤68 dB
S/N at 3KHz Dev.	≥40 dB
Audio Output Power At THD 10%	≥2.5 W
Audio Distortion	≤10 %
Audio Response	+1 to -3dB of 6dB/octave from 300hz to 3kHz dB
Current Drain : Max Audio Power	≤1.5 A
Current Drain : Stand-By	≤0.5 A
2ND RX Sensitivity For 12dB SINAD	≤0 dBuV(EMF)
2ND RX bit error ratio@-107dBm	≤ 10-2
Frequency error	≤±1.5KHz
RF Power	Hi23W ± 2W :Lo 0.8W ± 0.2W Hi23W ± 2W :Lo 0.8W ± 0.2W
Maximum Deviation Maximum Deviation	≤± 5 KHz
S/N at 3KHz Dev.	≥40 dB
Modulation Distortion ±3KHz	≤10 %
Audio Response at 1KHz Dev.	+1 to -3dB of 6dB/octave from 300hz to 3KHz
Spurious/Harmonic Emissions: Hi/LO	≤0.25uW
Modulation Sensitivity	≤15 mV
Current Drain At 12V DC	Hi Power ≤6A: Lo Power ≤1.5A
DSC TX deviation at 1.3K	2.6±0.26 KHz
DSC TX deviation at 2.1K	4.2±0.42KHz
ATIS TX deviation at 1.3 KHz	1.3±0.13 KHz
ATIS TX deviation at 2.1 KHz	2.1±0.21 KHz

What's in the Box:

RS20S VHF
S...

NMEA 2000 = Yes
Built-In GPS = Yes
AIS = No
Scrambler Capable = No
Remote Mic Capable = No
Hailer = No
Color = Black
