Blue Sea Systems Battery Switch Dual Circuit Plus Black - 6011200

(No ratings yet)

Key item features

Circuit Operation: This m-Series Mini Dual Circuit Plus Battery Switch in black simultaneously switches two isolated battery banks or combines them to all loads, featuring a make-before-break contact design for uninterrupted power.
Robust Ratings: It offers a continuous rating of 300A, an intermittent rating of 450A (5 min), and cranking ratings of 1000A (10 sec) and 650A (1 min), with a maximum voltage of 32V DC.
Physical Specifications: The switch has 3 positions, accepts two battery inputs, and requires 4/0 AWG cables for optimal performance, with 1.12 inches of clearance for these cables.
Installation Details: Designed for secure mounting, it accepts #10 screws for installation and features 3/8"-16 (M10) terminal studs requiring a torque of 120 in-lb (13.56 Nm).
Compact Dimensions: Weighing 0.80 lb (0.36 kg), the product comes in a box with dimensions of 3"H x 4"W x 7"L, making it a compact solution for battery management.
Safety Warning: This product contains chemicals, including di(2-ethylhexyl)phthalate (DEHP), known to the State of California to cause cancer, birth defects, or other reproductive harm.
