Hero image 0 of XDM1041 Bench-Type Digital Multimeter True RMS Universal Desktop Multimeters, 0 of 12

XDM1041 Bench-Type Digital Multimeter True RMS Universal Desktop Multimeters

Name: XDM1041 Bench-Type Digital Multimeter True RMS Universal Desktop Multimeters
Brand: JadeBamboo
SKU: 5092392904
Price: 144.19 USD
Availability: OutOfStock

(No ratings yet)

XDM1041 Bench-Type Digital Multimeter True RMS Universal Desktop Multimeters XDM1041 Bench Type Digital Multimeter True RMS Universal Desktop Multimeters

Actual Color:US Plug-Out of stock

selected, US Plug, $144.19, was $345.78, Out of stock

$345.78

Key item features

+ 55,000 counts, DC voltage accuracy up to 0.05%
+ Up to 65 readings per second
+ True RMS AC voltage / current measurement
+ Data record function, you can record the measured data into internal memory, and then read and process the recorded data with your computer
+ Dual line display supported

Specs

Multimeter type
Digital
Brand
JadeBamboo
Display
LCD
Model
WYM-231024330
Screen size
3.7"
Has written warranty
No

Current price is Now $144.19

You save $201.59

was $345.78

Price when purchased online

Out of stock

How do you want your item?

Out of stock

Report an issue with this seller

About this item

Product details

Features
+ 55,000 counts, DC voltage accuracy up to 0.05%
+ Up to 65 readings per second
+ True RMS AC voltage / current measurement
+ Data record function, you can record the measured data into internal memory, and then read and process the recorded data with your computer
+ Dual line display supported
+ SCPI support
+ Using our powerful and easy to use interface, you can access, store, process and manage your data, by simply displaying your results in form of a table.
+ 3.5 inch high-resolution LCD, providing a clear display

Specifications:
Display: 3.7-inch TFT LCD (480*320 resolution) Max.
Display: 55,000 counts
DC Voltage: 50mV~1000V
AC Voltage: 500mV~750V
DC Current: 500μA~10A
AC Current: 500μA~10A
Resistance: 500Ω~50MΩ
Frequency: 10Hz~60MHz
Capacitance: 50nF~50mF
Diode: 3.000V Continuity: 1000Ω
Temperature: K type, PT100 (K-type temperature probe is NOT included.)
Data Logging Duration: 15ms~9999.999s Data
Logging Length: 1,000 points
Warm-up Time: 30 minutes
Programmer Language: Standard SCPI, compatible with commands of main stream multimeters.
Item size: 200*86.5*64mm

Packing list
1*Portable Bench Multimeter
1*Power Cord
1*Fuse
1 pair of Alligator Clips
1 pair of Multimeter Leads
1*Quick Guide

Performance SpecificationsMeasurement RangeResolutionAccuracy ±(% of reading + % of range)DC Voltage50.000mV0.001mV0.1%+10500.00mV0.01mV0.05%+55.0000V0.0001V0.05%+550.000V0.001V0.05%+5500.00V0.01V0.1%+51000.0V0.1V0.1%+10AC VoltageVoltage 500mv-750v20Hz~45Hz1% +3045Hz~65Hz0.5%+3065Hz~1KHz0.7%+30DC Current500uA0.01uA0.15%+205000uA0.1uA0.15%+1050mA0.001mA0.15%+20500mA0.01mA0.15%+105A0.0001A0.5%+1010A0.001A0.5%+10AC Current500uA-500mA/0.5%+205A-10A1.5%+20Resistance(Ω)500Ω0.01Ω0.15%+105KΩ0.0001KΩ0.15%+550KΩ0.001KΩ0.15%+5500KΩ0.01KΩ0.15%+55MΩ0.0001MΩ0.3%+550MΩ0.001MΩ1%+10Capacitance(F)50nF-500uF/2.5%+55mF-50mF5%+10Frequency response(Hz)10.000Hz–60MHz/±(0.2%+10)Diode3.0000 V0.0001V/Continuity1000 Ω0.1ΩAdjustable thresholdTemperatureK type，PT100Max Display55,000 countsData-logging FunctionLogging Duration15ms-9999.999sLogging Length1,000 pointsGeneralDisplay Screen3.5-inch TFT LCD with resolution 480*320Dimensions (WxHxD)235 x 88x 64 (mm)Device WeightApproximately 0.45kgAccessoriesPower Cord、Alligator Clip、Fuse、Multimeter Lead、Quick、Guide

+ 55,000 counts, DC voltage accuracy up to 0.05%
+ Up to 65 readings per second
+ True RMS AC voltage / current measurement
+ Data record function, you can record the measured data into internal memory, and then read and process the recorded data with your computer
+ Dual line display supported

info:

We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here, and we have not verified it.

Specifications

Multimeter type

Digital

Brand

JadeBamboo

Display

LCD

Model

WYM-231024330
