HABOTEST HT113C 6000 Counts Digital Multimeter,DC AC Voltmeter,Ohm Volt Amp Meter,Measures Voltage,Current,Resistance,Continuity,Diodes,Electric Tools for Househould Outlet

The HABOTEST HT113C digital multimeter is a highly sophisticated device. It offers an extensive range of measurement capabilities. In terms of DC voltage, it can measure 600mV, 6V, 60V, and 600V. The AC voltage measurement range is also 600mV, 6V, 60V, and 600V. For DC current, it spans 600uA, 6000uA, 60mA, 600mA, and 10A, and the AC current range is identical. The resistance measurement range includes 600 Ω, 6k Ω, 60k Ω, 600k Ω, 6M Ω, and 60M Ω.It features a 6000-count display and operates in automatic range mode, providing convenience and accuracy. The NCV function, accompanied by LED and buzzer alerts, is available for non-contact voltage detection. It is capable of diode testing and has a maximum data retention feature. It also supports true effective value measurement, which is crucial for accurate readings. The bandwidth ranges from 40 to 1KHz, and it comes with work lights for enhanced visibility during operation.Meeting the security level of CAT III 600V, it can be used at altitudes below 2000m. The working temperature and humidity conditions are 0 to 40 ℃ (< 80% RH, < 10 ° C non-condensing), and for storage, the temperature and humidity should be -10 to 60 ° C (< 70% RH, with the battery removed). The temperature coefficient is 0.1 x accuracy/°C (< 18 ℃ or>28 ° C). The maximum allowable voltage between the measuring end and the ground is 600V. It has fuse protection with an F600mA/250V fuse tube for the MA range and an F10A/250V fuse for the 10A gear. The sampling rate is approximately 3 times per second.When the measurement exceeds the range, it indicates "OL". A "battery symbol" is displayed when the battery voltage is low. The input polarity is automatically shown with the "one" sign. Powered by 2x1.5V AAA batteries, it is a reliable and versatile tool for a wide array of electrical measurement tasks.it serves as an ideal Thanksgiving or Christmas gift for family and friends.
