500 lbs Lightweight Hand Operated Lift Truck with Fixed Legs

The Compact Lift Truck is used to lift material to and from shelves, move office equipment and install ceiling and wall appliances. Perfect when aisles and congested areas prevent the use of larger equipment. Rolls through standard doorways in the upright position without having to tilt back the truck. Constructed of durable steel and lightweight aluminum frame, with 4"W x 1-3/4" thick steel forks that measure 20-1/2"W x 22"L overall. Forks can be inverted to provide two different lift heights. Unit is operated by a hand-crank winch that features a folding handle and a hold-down device for securing the carriage during transport. Rolls easily on 8" non-marking rubber rear wheels and 2" front swivel casters. Lightweight and portable, as upper handle rollers allow the truck to be loaded onto its back for easy van or pickup transporting.

• Built to match your exact requirements
• Provides exceptional reliability
• Made with the finest materials to provide premium quality

• Length Inches: 34-1/2
• Width Inches: 24
• Height Inches: 67
• Capacity Lbs: 500
• Color Finish: Silver & Blue
• Assembly: Unassembled
• Construction: Aluminum & Steel
• Fork Length Inches: 22
• Fork Width Inches: 4
• Lowered Height Inches: 3-1/2 Forks Down; 21-1/4 Forks Up
• Power: Manual Winch Operated
• Raised Height Inches: 47 Forks Down; 70 Forks Up
• Straddle Leg Width Inches: 12-3/4 I.D.; 24 O.D.
• Truck Style: Fixed Legs
• Type: Forks
• Wheel Type: 8" Rubber Rear & 2" Rubber Swivel
• Material 1: Aluminum & Steel
• Dimension 1: 68" H x 25" W x 35" L
• Weight: 165 lbs
