General Tools & Instruments HWA4214SD Data Logging Hot Wire Aneometer W- Excel Formatted Sd Card

Accurately measures air (wind) speeds as low as 0.5 mph and air temperatures within ±1.5°F (± 0.8°C).

Features & Benefits :

Includes telescoping air speed-temperature
probe

Displays air (wind) speed in meters/second,
feet per minute, kilometers/hr, knots (nautical
miles per hour), or miles per hour

Measures air speeds down to 0.2 m/sec with
0.01 m/sec resolution (down to 40 ft/min with

ft/min resolution)

Displays temperature in °F or °C

Big (2.5 in. diagonal) front-panel green backlit
LCD is easy to read

Displays maximum and minimum readings and
holds any reading

Automatically logs measurements at sampling
time settable from one second to one hour

Also supports manual data logging and
changing of SD card storage location

Auto power off function


Specifications :

  Display: 2.05 x 1.5 in. (52 x 38mm) LCD
  Parameters Measured: Air speed, temperature
  Measurement Range:

For air speed: 0.2 to 25 m/sec, 0.7 to 172
km/hr, 0.5 to 44.7 mph, 0.4 to 38.8 knots,
40 to 3940 ft/min

For temperature: 32° to 122°F (0° to 50°C)
  Measurement Accuracy:

For air speed: ± (5% + 0.1 m/sec),

(5% + 0.3 km/hr), ± (5% + 0.2 mph),

(5% + 0.2 knots), ± (5% + 20 ft/min)

For temperature: ± 1.5°F (± 0.8°C)
  Data Logging Sampling Time: 1 second to

hour
  Settable Parameters: Date, time, auto power off,
beep sound, sampling time, decimal point or
comma decimal division, temperature unit, air
speed unit, optional thermocouple type (K or J)
  Storable/Recallable Readings: Maximum,
minimum
  Operating Temperature:
32° to 122°F (0° to 50°C)
  Operating Relative Humidity: 0 to 85%
  Dimensions of Instrument:
7.99 x 2.99 x 1.50 in. (203 x 76 x 38mm)
  Weight of Instrument: 1.13 lb. (515g)
  Dimensions of Probe: 0.4724 in. (diameter) x
11.02 in.(collapsed)/37 in.(extended)
(12mm x 280mm/940mm)
  Power Source: 6 “AA” batteries or optional
9-VDC AC adapter
Includes :

Hard carrying case

Telescoping air speed/temperature probe

2 GB SD memory card

User’s manual

1 Year Limited - SKU: GNRL211
