Eastwood HotCoat® PCS-250 Powder Coating System and Benchtop Oven Kit
Key item features
- Dual Voltage: The PCS-250 powder coating gun operates on standard 120v household current with two settings: a low 15,000-volt setting for small areas and a high 25,000-volt setting for larger surfaces and multi-coat coverage.
- Enhanced Gun Features: The powder coating gun includes a clear bottle to monitor powder color and level, larger internal passages for improved powder flow, color-coded cabling, an increased trigger room, and a new improved ground clamp.
- Compact Oven: The HotCoat Benchtop Powder Coating Oven is ideal for small to mid-size projects, offering a generous internal volume of 1.2 ft³ (34L) within overall dimensions of 20.55" x 15.47" x 13.19".
- Precise Heat Control: The oven features selectable upper and lower heating elements (2x 400W each) and an air circulation fan, allowing for optimum control of heat distribution and a temperature range of 150 - 400°F.
- Convenient Curing: A built-in timer (0-60 minutes) and an oven door window provide a convenient view of parts during the critical flow-out stage, enabling proper setting for desired cure times.
Specs
- BrandEastwood
- Toaster oven typeToaster Oven
- Holding capacity1.2 ft3 (34L)
- Maximum temperature400ºF
- Dimensions20.55 x 15.47 x 13.19 "
- Volume capacity1.2 cu ft
- Free shipping
Free 90-day returns
(Only one option can be selected at a time)
How do you want your item?
About this item
Product details
PCS-250 Powder Coating Gun
The Eastwood PCS-250 Dual-Voltage HotCoat™ Powder Coating Gun gives you complete coverage from tight areas to large surfaces while operating on standard 120v household current. This innovative system will allow you to achieve the benefits of powder coating small parts instead of coating them with paint. This new and improved dual-voltage system gives you the capability to coat small areas using the low 15kv setting or coat large areas using the high-voltage setting 25kv. All you need is a compressed air source (5-10 PSI from a portable tank with a regulator or a compressor) to power your gun, an electric oven or toaster oven to cure the finish and a well-ventilated workspace in which to do your coating. This new and improved gun features color-coded cabling, larger ground clamp, increased trigger room and a clear bottle so you can see the powder color and fluidizing action.
Hotcoat Benchtop Powder Coating Oven
The Eastwood Hotcoat Benchtop Powder Coating Oven combines generous internal volume in a convenient, compact package with big oven features.
This oven has selectable upper and lower Heating Elements, and air Circulation Fan allow optimum control of heat distribution inside the Oven. The Oven Door window presents a convenient view of parts during the critical “flow-out” stage, enabling proper setting of the built-in Timer for the desired cure time. Couple this oven with any of Eastwood’s HotCoat Powder Coating Guns and start coating brackets, housings, and other small to medium-sized parts right in your home shop or garage.
PCS-250 Specifications
15KV/25KV dual voltage output
New and improved ground clamp provides a better ground
Color coordinated cabling for easier setup
New clear bottle makes it easy to see powder level and fluidizing action
Additional 1/2" of trigger room makes it easier and more comfortable to use
Powder Coating Oven Specifications
Electrical Rating: 120V / 50/60Hz / 1 Ph
Heating Power: 1600W
Heating Elements: Top: 2x 400W / Bottom: 2x 400W
Minimum Ambient Temperature: 50°F
Oven Chamber Temperature Range: 150 - 400°F
Timer Range: 0-60 Minutes
Circulation Fan: Yes
Rack Levels: (Top / Middle / Bottom)
Internal Volume (W x D x H): 15.12" x 12.83" x 10.71" (384 x 326 x 272mm) 1.2 ft3 (34L)
Power Cord Length: 31.5" (0.80m)
Overall Dimensions: 20.55" x 15.47" x 13.19" (522 x 393 x 335mm)
Weight: 14.6 lbs (6.62kg)
Certification: ELT
Product Weight: 8.2 lbs.
- Powder Coating Gun Operates on standard 120v / 60Hz household current
- Versatility with two settings for improved coverage - Low 15,000-volt setting and High 25,000-volt setting for multi-coat coverage over larger areas
- Clear bottle allows you to see powder color, level and fluidizing action and Larger internal passages for improved powder flow
- Oven is Ideal for Small to Mid-Size Powder Coating Projects
- Oven Heats Up Fast With Upper and Lower Heating Elements and Air Circulation Fan Allow Optimum Control of Heat Distribution
Specifications
Brand
Toaster oven type
Holding capacity
Maximum temperature
Warranty
Warranty information
Warnings
Warning Text
WARNING - California Proposition 65 - www.P65Warnings.ca.gov
