(8) JBL GSF3-GN 3" Landscape Ground Stake/Wall 70v Commercial Speakers+Amp

(No ratings yet)

Key item features

Package Includes: (4) Pair JBI GSF3-GN 3" Landscape Ground Stake or Wall Mount 70v Commercial Speaker. (1) Rockville RCS180-6 180 Watt 6 Zone 70v Commercial/Restaurant Amplifier/Bluetooth. Features: Transducers: 83 mm (3") woofer with polypropylene cone and 25 mm (1") voice coil on Kapton voice coil former; 20 mm (0.8 in) titanium dome tweeter with neodymium magnet assembly and Kapton voice coil former. Frequency Range: 74 Hz - 20 kHz
Power handling (at 8? setting): 30W continuous pink noise, 60W continuous program. IP66 rated against water and dust ingress. Multi-tap 15W transformer is switchable for 8O direct operation or use in 70V/100V distributed systems. Bottom drip hole provides drainage for drivers. Pairs well with JBI GSB8 and GSB12 in-ground landscape subwoofers. Aimable via adjustable hinge. Includes ground stake and L-bracket for surface mounting
Includes tap selector located on bottom of speaker, away from water incursion. Available in hunter green or tan finish. Specifications: Frequency Range (-10dB): 74 Hz - 20 kHz. Frequency Response (+/-3 dB): 120 Hz - 15 kHz. Power Rating: 60 W Continuous Program (2 hrs), 30 W (120 W Peak), Continuous Pink Noise (2 hrs), 20 W (80 W Peak), Continuous Pink Noise (100 hrs). Sensitivity: 84 dB (43 Hz - 110 Hz). Maximum SPL: 103 dB peak (95 dB continuous, 2 hr) @ 1m. Coverage Pattern: 90° conical
Nominal Impedance: 8 ? (at 8? tap). Transformer Taps: 70V: 15 W, 7.5 W, 3.75 W, 100V: 15 W, 7.5 W. Drivers: 83 mm (3 in) woofer, polypropylene cone 25 mm (1 in) voice coil on Kapton voice coil former, 20 mm (0.8 in) titanium dome, Neodymium magnet assembly, Kapton voice coil former. Terminals: Bare wire with dielectric-gel-filled wire nuts (1 meter single jacked cable 2 wires with 18 AWG). Enclosure Material: Polycarbonate + ABS, UL94V-0 flammability rated
Color: Hunter Green RAL 6018, or Tan RAL7004. Dimensions: Cabinet 132 mm diameter x 167 mm deep (5.2 x 6.6 in). Assembly height 289 mm (11.4 in) with L-bracket base (at 90°) and 430 (17.0 in) with ground stake base. Net Weight: 1.7 kg (3.8 lbs). Included Accessories: (1) Ground Stake Bracket; (1) L-Bracket. Directivity Factor (Q): 7.9. Directivity Index (dB): 9 dB. Includes: Amplifier. Remote. Rack mount ears. Power Cable. FM Radio antenna. Owner's manual. Warranty. Applications: Restaurant

Specs

Home speaker & subwoofer type
Wall Mount Speakers
Recommended location
Outdoor
Brand
JBL
Color
Green
Wireless
Y
Woofer size
3 in

Current price is $1,559.75

Price when purchased online

Out of stock

How do you want your item?

Out of stock

About this item

Product details

This commercial outdoor audio bundle includes eight JBL GSF3-GN 3-inch landscape speakers and one Rockville RCS180-6 six-zone amplifier. Supplied as four pairs in a hunter green finish, the system is designed for distributed background music and announcements in shopping areas, theme parks, sports venues, hospitality properties, restaurants, schools, offices, warehouses, and other multi-speaker locations.

Each JBL GSF3-GN uses a two-way coaxial design with a 3-inch polypropylene-cone woofer and a 0.8-inch titanium dome tweeter. The speaker covers 74 Hz to 20 kHz with 90-degree conical dispersion and reaches up to 103 dB peak SPL. Its 15W multi-tap transformer supports 70V settings of 15W, 7.5W, and 3.75W, 100V settings of 15W and 7.5W, plus direct 8-ohm operation.

The IP66-rated polycarbonate and ABS enclosure helps protect each speaker from water and dust during outdoor installation. Every speaker includes a ground stake for landscape placement and an L-bracket for horizontal or vertical surface mounting. An adjustable hinge allows precise aiming, while the bottom drainage hole and attached one-meter, two-conductor 18 AWG cable support practical setup.

The Rockville RCS180-6 provides up to 180W for 70V distributed systems and can divide output across six zones with separate volume controls. It also supports 100V, 8-ohm, and 4-ohm applications. Bluetooth, FM radio, USB, SD card, RCA AUX, optical input, and RCA line output accommodate multiple sources, while three microphone inputs with echo controls and a chime button support paging and presentations.

Additional amplifier features include bass and treble adjustment, individual microphone level controls, a clipping limiter, and a built-in cooling system. Detachable euro-block terminals simplify speaker wiring, and removable rack ears support 19-inch rack installation. The amplifier also includes a remote, power cable, and FM antenna, completing a multi-zone commercial audio system.

Package Includes: (4) Pair JBI GSF3-GN 3" Landscape Ground Stake or Wall Mount 70v Commercial Speaker. (1) Rockville RCS180-6 180 Watt 6 Zone 70v Commercial/Restaurant Amplifier/Bluetooth. Features: Transducers: 83 mm (3") woofer with polypropylene cone and 25 mm (1") voice coil on Kapton voice coil former; 20 mm (0.8 in) titanium dome tweeter with neodymium magnet assembly and Kapton voice coil former. Frequency Range: 74 Hz - 20 kHz
Power handling (at 8? setting): 30W continuous pink noise, 60W continuous program. IP66 rated against water and dust ingress. Multi-tap 15W transformer is switchable for 8O direct operation or use in 70V/100V distributed systems. Bottom drip hole provides drainage for drivers. Pairs well with JBI GSB8 and GSB12 in-ground landscape subwoofers. Aimable via adjustable hinge. Includes ground stake and L-bracket for surface mounting
Includes tap selector located on bottom of speaker, away from water incursion. Available in hunter green or tan finish. Specifications: Frequency Range (-10dB): 74 Hz - 20 kHz. Frequency Response (+/-3 dB): 120 Hz - 15 kHz. Power Rating: 60 W Continuous Program (2 hrs), 30 W (120 W Peak), Continuous Pink Noise (2 hrs), 20 W (80 W Peak), Continuous Pink Noise (100 hrs). Sensitivity: 84 dB (43 Hz - 110 Hz). Maximum SPL: 103 dB peak (95 dB continuous, 2 hr) @ 1m. Coverage Pattern: 90° conical
Nominal Impedance: 8 ? (at 8? tap). Transformer Taps: 70V: 15 W, 7.5 W, 3.75 W, 100V: 15 W, 7.5 W. Drivers: 83 mm (3 in) woofer, polypropylene cone 25 mm (1 in) voice coil on Kapton voice coil former, 20 mm (0.8 in) titanium dome, Neodymium magnet assembly, Kapton voice coil former. Terminals: Bare wire with dielectric-gel-filled wire nuts (1 meter single jacked cable 2 wires with 18 AWG). Enclosure Material: Polycarbonate + ABS, UL94V-0 flammability rated
Color: Hunter Green RAL 6018, or Tan RAL7004. Dimensions: Cabinet 132 mm diameter x 167 mm deep (5.2 x 6.6 in). Assembly height 289 mm (11.4 in) with L-bracket base (at 90°) and 430 (17.0 in) with ground stake base. Net Weight: 1.7 kg (3.8 lbs). Included Accessories: (1) Ground Stake Bracket; (1) L-Bracket. Directivity Factor (Q): 7.9. Directivity Index (dB): 9 dB. Includes: Amplifier. Remote. Rack mount ears. Power Cable. FM Radio antenna. Owner's manual. Warranty. Applications: Restaurant
