Honeywell L404F1060 Pressuretrol Controller Auto Recycle 2 psi to 15 psi Features: Use with steam, air, noncombustible gases, or fluids non-corrosive to pressure sensing element. Models have snap-acting switching to open or close a circuit on pressure rise. Have adjustable differentials. Adjustments are made by screws on top of case. Mount using 1/4 inch -18 NPT internal pipe threads or surface mount through base of case. Ground screw terminal. Product Specifications: Application: Provide control of steam, air, non-combustible gases or non-corrosive fluids Dimensions (in.): 4-27/32 in. high x 4-1/2 in. wide x 3-1/4 in. deep Dimensions (mm): 123 mm high x 114 mm wide x 83 mm deep Mounting: 1/4 in. NPT internal thread or surface mount through back of case Approvals, Underwriters Laboratories Inc: Listed: File No. MP466, Guide No. MBPR Approvals, CSA: Certified: File No. LR1620, Guide No. 400-E-O Electrical Connections: Screw terminals Contact Ratings: 120 Vac Switch Contact-- 8.0 AFL, 48.0 ALR, 10.0 A resistive; 240 Vac Switch Contact-- 5.1 AFL, 30.6 ALR, 5.0 A resistive Operating Temperature Range (F): -35 F to +150 F Operating Temperature Range (C): -37 C to +66 C Approvals, Swiss RE: Acceptable Sensor Element: Stainless Steel diaphragm Operating Range (psi): 2 to 15 psi; 25 psi - Maximum Sustained Operating Range (kPa): 14 to 103 kPa; 172 kPa - Maximum Sustained Differential Pressure Range (psi): 2 to 6 psi Differential Pressure Range (kPa): 14 to 41 kPa Differential Type: Subtractive Switch Operation: Auto recycle Switching Action: SPDT snap action, make R-W, break R-B on pressure rise Pipe Connection: Main or High Pressure--1/4 in. NPT internal thread Replaces Honeywell L404F1003, Honeywell L404H1001, Honeywell L404H1019, Honeywell L404H1035
