HellermannTyton CAT5e RJ45 Insert - Red, RJ45FC5E-RED

When using HellermannTyton's modular jacks the GigaBand far exceed the TIA requirements for structured cabling systems. HellermannTyton's modular jacks are an integral part of the Category 5e systems, offering quality, versatility, and reliability.

• RJ45 terminated to a 110 IDC PCB connector
• Jack life up to 1,000 insertions
• Contact set constructed of phosphor bronze material with 50 micro-inch gold plating
• Components manufactured from UL94V-0 thermoplastic material
• Unique strain relief design secures cable terminations
• Innovative crosstalk cancellation technology 10 internal contacts (two extra to cancel out crosstalk) and 8 external contacts in standard configuration to accept industry standard patch cords
• Staggered contacts provide superior performance
•
  Versatility:
• Configured with both 568A and 568B wiring schemes
• IDC accepts 22-26 AWG solid twisted-pair cable
•
  Reliability:
• RJ45 jacks are factory tested 200 times with an RJ11 plug (4P or 6P) to ensure there is no damage to the contacts
• Each jack is individually tested three times to ensure quality performance
• IDC is factory tested to 50 terminations
•
  Specifications:
• Quantity: 1
• Color: Red
• Category: 5e
•
