SDJMA HD 7" Car Rearview Monitor with Multi-Input & Remote Control,Home Decor Collection

High Definition Multifunctional Computer LCD Display Screen

Parameters:

Screen size: 7 inches

Resolution: 800 * 480RBG/1024 * 600

Standard:NTSC

Power supply: DC12V (24-33V can be customized)

Power consumption: approximately 7W

Video: 2-channel video input (customizable audio)

The rearview image can be flipped up/down/left/right by mirroring

All functions can be remotely operated, and the buttons on the machine can also be fully operated

ability：

1. Key function description:

2). You can select the adjustment parameter downwards in the MENU menu

3). MENU key: Press this keyboard to cycle through the adjustment menu

4). +"plus key: can select adjustment parameters up in the MENU menu

5). POWER button: power on/off button

2. Mandatory Function Description:

3. Key: The image screen can be flipped up/down/left/right by mirroring

This monitor can be used as a desktop/stand, mounted on a headrest, or made into a headrest package monitor, providing customers with more and better choices

characteristic:

Widely used in transportation vehicles such as buses, container trucks, commercial vehicles, trucks, engineering vehicles, fire trucks, ships, etc.

1. The system has DC12/24V input, making installation more convenient and widely used in various vehicles. Suitable for cold vehicles with unstable power supply voltage, built-in overheating and overcurrent protection function

2. Reverse priority function, automatically switches the reverse screen when reversing in any state, returns to state after reversing, and realizes the automatic wake-up function of reversing;

3. Can connect two video inputs ( can connect one external DVD/camera audio and video , AV2: supports one reverse )

4. The reverse screen can be manually on the monitor.

5. 7-inch car display, featuring realistic colors, and stable system.

Function Description: (7 "Car Rear View System)

·Supports 2 video inputs, (can be customized as three inputs or one audio input or with card slot according to customer requirements) ...)

·Color system: NTSC (SECAM system can be customized)

Manual or automatic switching of video ·Brightness, contrast, and field synchronization adjustment functions

Width 200mm x Height 125mm x Thickness 40mm

Includes: 1x car monitor, 1x remote control, 1x power cord, 1x manual, 1x bracket, 1x double-sided adhesive tape
