Hero image 0 of General Tools & Instruments DSM403SD Class 1 Sound Level Meter With Excel-Formatted Data Logging Sd Card, 0 of 1
General Tools & Instruments DSM403SD Class 1 Sound Level Meter With Excel-Formatted Data Logging Sd Card
(No ratings yet)
Key item features
- Precise Measurement: Accurately measures sound levels from 30 to 130dB with 0.1 dB resolution, featuring A or C frequency weighting and fast or slow time weighting (200ms or 500ms response).
- Versatile Logging: Supports automatic data logging with a sampling time settable from 1 second to 1 hour, and also allows for manual logging and changing of card storage location.
- Clear Display: Features a large 2.5-inch diagonal, green backlit LCD for easy reading of measurements, including maximum and minimum readings.
- Configurable Settings: User-settable parameters include date, time, auto power off, beep sound, sampling time, decimal division, and frequency/time weighting.
- Portable Design: Weighs 1.08 lb. (489g) and measures 9.65 x 2.68 x 1.77 inches, powered by 6 AA batteries or an optional 9-VDC AC adapter.
- Included Accessories: Comes with a hard carrying case, sound wind shield ball, and a 2 GB SD memory card for immediate use.
Generated by AI
Specs
- Maximum sound pressure level130 dB
- Freq range31.5Hz to 16kHz
- BrandGeneral Tools
- Power typeBattery
- Has written warrantyNo
- Weight1.08 lbs
Current price is USD$432.47
Price when purchased online
- Free shipping
Free 30-day returns
How do you want your item?
Columbus, 43215
Arrives by Thu, Mar 19
|
Sold and shipped by UnbeatableSale Local
4.1044216022189595 stars out of 5, based on 6129 seller reviews(4.1)6129 seller reviews
Free 30-day returns - in store or online
More seller options (1)
Starting from $434.52
Similar items you might like
Based on what customers bought
Class 2 Data-Logging Decibel Meter PCE-SDL 1 $296.00
$29600current price $296.00Class 2 Data-Logging Decibel Meter PCE-SDL 1
LAMIRO Decibel Meter Digital Sound Level Meter Professional Noise Meter High Accuracy 30dB to130dB Measuring Range with Backlight Display for Office, Home $12.50
$1250current price $12.50LAMIRO Decibel Meter Digital Sound Level Meter Professional Noise Meter High Accuracy 30dB to130dB Measuring Range with Backlight Display for Office, Home
Adifare Digital Decibel Meter High Precision Sound Level Reader Noise Volume Measure Device with LCD Backlit Battery Operated Decibel Reader Record for Noise Control $25.59 Was $32.99
$2559current price $25.59, Was $32.99$32.99Adifare Digital Decibel Meter High Precision Sound Level Reader Noise Volume Measure Device with LCD Backlit Battery Operated Decibel Reader Record for Noise Control
Sound Level Detector With Built In Memory For Long Term Noise Data Recording $21.42
$2142current price $21.42Sound Level Detector With Built In Memory For Long Term Noise Data Recording
Reed Instruments Sound Level Meter,Max Frequency 8 kHz R1620-KIT $416.30
$41630current price $416.30Reed Instruments Sound Level Meter,Max Frequency 8 kHz R1620-KIT
Decibel Meter PCE-SLT-TRM-24V $455.00
$45500current price $455.00Decibel Meter PCE-SLT-TRM-24V
30-130dB Decibel Meter Noise Measuring Instrument with A/C Weighted Data Hold SPL Tester Digital Sound Level Meter $25.00
$2500current price $25.0030-130dB Decibel Meter Noise Measuring Instrument with A/C Weighted Data Hold SPL Tester Digital Sound Level Meter
Noise Meter / Sound Meter PCE-SLT-TRM $470.00
$47000current price $470.00Noise Meter / Sound Meter PCE-SLT-TRM
Digital Decibel Meter Sound Level Reader Sound Meter for Accurate Noise Measurement in homes Office Construction site $21.61
$2161current price $21.61Digital Decibel Meter Sound Level Reader Sound Meter for Accurate Noise Measurement in homes Office Construction site
Decibel Meter PCE-323 $339.00
$33900current price $339.00Decibel Meter PCE-323
StarTech.com Handheld Digital Sound Meter w/Large LCD, Noise/Decibel Level Reader for Server Rooms/Offices, Audio Monitor, 30-130dBA Range $44.99
$4499current price $44.99StarTech.com Handheld Digital Sound Meter w/Large LCD, Noise/Decibel Level Reader for Server Rooms/Offices, Audio Monitor, 30-130dBA Range
15 out of 5 Stars. 1 reviewsHFS(R) Sound Meter, Sound Level Meter, Noise Meter, Decibel Meter, Sound Analyzer, Range 30dB to 130dB with Backlight LCD Display, Data Hold, for Home, Office, School $24.99
$2499current price $24.99HFS(R) Sound Meter, Sound Level Meter, Noise Meter, Decibel Meter, Sound Analyzer, Range 30dB to 130dB with Backlight LCD Display, Data Hold, for Home, Office, School
RadioShack Digital Sound Level Meter, model 33-2055 $150.00
$15000current price $150.00RadioShack Digital Sound Level Meter, model 33-2055
Sound Level Meter with Datalogger PCE-325D $199.00
$19900current price $199.00Sound Level Meter with Datalogger PCE-325D
Clearance High Precisions Sound Leveling Meter Decibel Noise Tester Digital Noise Meter Simple to Use for Environmental Monitoring $14.52 Was $17.37
Clearance
$1452current price $14.52, Was $17.37$17.37High Precisions Sound Leveling Meter Decibel Noise Tester Digital Noise Meter Simple to Use for Environmental Monitoring
Gn102 Mini Decibel Meter Hd Screen Display Db Noise Meter 30-130Db Sound Tester $19.99
$1999current price $19.99Gn102 Mini Decibel Meter Hd Screen Display Db Noise Meter 30-130Db Sound Tester
15 out of 5 Stars. 1 reviewsSound Level Meter 30-130dBA, Professional Decibel Meter with Backlit Display (9V Battery Included) $19.30
$1930current price $19.30Sound Level Meter 30-130dBA, Professional Decibel Meter with Backlit Display (9V Battery Included)
DURATOOL - A and C Weighted Digital Sound Level Meter - 30dB to 130dB $167.23
$16723current price $167.23DURATOOL - A and C Weighted Digital Sound Level Meter - 30dB to 130dB
Sound Level Meter with Large LCD Full Screen, Wall Mounted Noise Meter,Digital Decibel Meter with Alarm, SPL Meter, Decibel Monitoring Tester 30-130dB Measuring Range $69.99
$6999current price $69.99Sound Level Meter with Large LCD Full Screen, Wall Mounted Noise Meter,Digital Decibel Meter with Alarm, SPL Meter, Decibel Monitoring Tester 30-130dB Measuring Range
Reduced price High Precision- VU Meter Digital Amplifier Pointer Type Analog- Audio DB- Sound $15.85 Was $17.71
Reduced price
$1585current price $15.85, Was $17.71$17.71High Precision- VU Meter Digital Amplifier Pointer Type Analog- Audio DB- Sound
About this item
Product details
Accurately measures sound levels of machinery or an environment with 0.1 dB resolution. Features & Benefits :
Big (2.5 in. diagonal) front-panel green backlit LCD is easy to read
Makes measurements in auto ranging mode or within a manually settable range
Displays maximum and minimum readings and holds any reading
Performs automatic data logging at sampling time settable from 1 second to 9 hours
Also supports manual logging and changing of card storage location
Auto power off function
Specifications :
Display: 2.05 x 1.5 in. (52 x 38mm) LCD Frequency Range: 31.5Hz to 16kHzMeasurement Range:· 30 to 130dB in auto ranging mode· User can also select fixed range of 30 to 80dB, 50 to 100dB, or 80 to 130dBMeasurement Weighting:· By frequency: frequency weighing uses “A” or “C” standard· By time: Using Class 1 IEC 61672 standard; time weighting is fast or slow (200ms or 500ms response time)Measurement Accuracy:· With “A” frequency weighting: ± 2.0dB @ 31.5Hz, 1.5dB @ 63Hz, 1.5dB @ 125Hz, 1.4dB @ 250Hz, 1.4dB @ 500Hz, 1.1dB @ 1kHz, 1.6dB @ 2kHz, 1.6dB @ 4 kHz, +2.1 dB and -3.1dB @ 8kHz; +3.0dB and -6.0dB @ 12.5kHz, +3.5dB and -17.0dB @ 16kHzData Logging Sampling Time: 1 second to 1 hour Settable Parameters: Date, time, auto power off, beep sound, sampling time, decimal point or comma decimal division, “A” or “C” frequency weighting, fast or slow time weighting Storable/Recallable Readings: Maximum, minimum Operating Temperature: 32° to 122°F (0° to 50°C)Operating Relative Humidity: 0 to 85%Dimensions: 9.65 x 2.68 x 1.77 in. (245 x 68 x 45mm)Weight: 1.08 lb. (489g)Power Source: 6 “AA” batteries or optional 9-VDC AC adapter
Includes :
· Hard carrying case
Sound wind shield ball
2 GB SD memory card
User's manual
1 Year Limited - SKU: GNRL216
Specifications :
Display: 2.05 x 1.5 in. (52 x 38mm) LCD Frequency Range: 31.5Hz to 16kHzMeasurement Range:· 30 to 130dB in auto ranging mode· User can also select fixed range of 30 to 80dB, 50 to 100dB, or 80 to 130dBMeasurement Weighting:· By frequency: frequency weighing uses “A” or “C” standard· By time: Using Class 1 IEC 61672 standard; time weighting is fast or slow (200ms or 500ms response time)Measurement Accuracy:· With “A” frequency weighting: ± 2.0dB @ 31.5Hz, 1.5dB @ 63Hz, 1.5dB @ 125Hz, 1.4dB @ 250Hz, 1.4dB @ 500Hz, 1.1dB @ 1kHz, 1.6dB @ 2kHz, 1.6dB @ 4 kHz, +2.1 dB and -3.1dB @ 8kHz; +3.0dB and -6.0dB @ 12.5kHz, +3.5dB and -17.0dB @ 16kHzData Logging Sampling Time: 1 second to 1 hour Settable Parameters: Date, time, auto power off, beep sound, sampling time, decimal point or comma decimal division, “A” or “C” frequency weighting, fast or slow time weighting Storable/Recallable Readings: Maximum, minimum Operating Temperature: 32° to 122°F (0° to 50°C)Operating Relative Humidity: 0 to 85%Dimensions: 9.65 x 2.68 x 1.77 in. (245 x 68 x 45mm)Weight: 1.08 lb. (489g)Power Source: 6 “AA” batteries or optional 9-VDC AC adapter
Includes :
· Hard carrying case
General Tools & Instruments DSM403SD Class 1 Sound Level Meter With Excel-Formatted Data Logging Sd Card
