Tower Light Module, 110/120V AC, Red, 70 mm Dia., 3 in Height, LED, SL4 Series SL7-L120-R

(No ratings yet)

Key item features

Color:Red
Compatible Series:SL4
Current Drawn:0.031A
Diameter:70 mm
For Location:Indoor, Outdoor
For Use With:SL4 Stacklights
IP Rating:IP66
Item:Tower Light Module
Lamp Life:100,000 hr
Lamp Type:Led
Lamp Watts:3.7 W
Length:2.87 in
Lens Design:Fresnel
Lens Material:Polycarbonate
Lens Shape:Cylinder
Lifespan:100,000 hr
Light Color:Red
Light Operating Mode:Steady
Light Source:LED
Lighting Technology:LED
Mounting:Screw Clamp
NEMA Rating:NEMA 13, NEMA 4, NEMA 4X
Number of Lamps:1
Operating Current:0.028 to 0.031 A
Operating Temp.:-22 Degrees to 140 Degrees F
Operating Temperature - Maximum:140 Degrees F
Operating Temperature - Minimum:-22 Degrees F
Operating Voltage:110/120V AC
Overall Diameter:70 mm
Overall Height:3 in
Rating:NEMA 4X, IP66
Standards:CE, CSA C22.2 No. 14-10, CSA C22.2 No. 94-91, CSA Certified, CSA Class No. NKCR7, cULus Listed, IEC Rated, UL 508, UL File E29184, UL Listed
Tower Light Color:Red
Tower Light Series:SL4
Voltage:110/120V AC
Wattage:3.7 W
Watts:3.7 W
Width:2.87 in
