DAE MJ-50R Lead Free Hot Potable Water Meter, 1/2" NPT Couplings, Pulse Output+Gallon

Lead-Free Hot Potable Water Meter, 1/2" NPT Couplings at both ends, with Pulse Pulse/Reed Switch Output, Multi-Jet. Model: DAE MJ-50R. Unit:US Gallon. Accuracy: +/-1.5% within normal flow rate range as per AWWA Standard. Pulse Output: 1 gallon/pulse, a dry contact (i.e. no voltage) reed switch with 2 wires, 1.5m. The switch may be damaged if input electricity is more than 0.01A, 24V. We shall not be responsible with the result if connecting to third party device which is not certified by DAE. Meter body: Lead-Free Brass. Length without couplings: 6.5 inches, Length with couplings: 10.2 inches. Item dimension: 6.5" length, 3.7" wide, 4.23" height. Weight: 2 lbs 11 once. NSF61 Certified Lead Free Couplings Included. Max. Reading:9,999,999 gallons, Min.Reading:0.005 gallons, The 1st digit from the right has a multiplier of 100 gallons. For example, if you see 01234 on the digits, it is 123400 gallons. The 1st dial under the digits has a multiplier of 10 gallons. The 2nd dial under the digits is in gallon. Reading on 4th picture of listing is 114.845 gallons. Max temperature: 194˚F (90˚C). Pressure drop: 1.020 psi @ 5 GPM, 1.900 psi @ 10 GPM. Conforms to AWWA C708, for City water only. Safe Maximum Flow Rate: 20 GPM, Recommended Maximum Continuous Flow Rate: 10 GPM, Minimum Test Flow Rate: 0.25 GPM, Normal Test Flow Limits: 1-20 GPM. DAE MJ-50 5/8"*1/2" meter is not a meter with a 5/8" inlet and a 1/2" outlet. It is with 1/2" NPT couplings for both 1/2" inlet and 1/2" outlet. The max. working pressure is 232 psi, exceeding the requirement from AWWA standard 150 psi. Bore diameter: 0.72 inch (18.3mm). For the buyers outside of USA, in addition to the tax, the carriers may charge brokerage fee.
