The CATIA V5-6R2017: Generative Drafting (ANSI) learning guide enables you to use the generative capabilities of CATIA V5 to create an ANSI drawing from a 3D solid Part. This course is appropriate for new CATIA V5 users.

Topics Covered
- Start a generative drawing
- Define the main views
- Define section views and cuts
- Define secondary views: detail, clipping, broken, breakout, auxiliary, isometric and unfolded views
- Edit a view and sheet properties
- Add sheets to a drawing
- Reposition views
- Modify section, detail and auxiliary profiles
- Modify section, detail and auxiliary graphical definitions
- Modify section hatching representations
- Create generative dimensions and tolerances
- Generate assembly drawings
- Create annotations and drawing tables
- Create balloons
- Check links to a solid 3D part and update a drawing
- Add a title block
- Print the drawing
- Set drafting options
Prerequisites
- CATIA V5-6 R2017: Introduction to Modeling, or
- CATIA V5-6 R2017: Introduction for Non-Designers
