Renogy 10A 1P DC Miniature Circuit Breaker

【DOUBLE SECURITY】Equipped with both the thermal and magnetic tripping mechanism for reliability and safety
【SAFE TO USE】Offers reversible connection for worry-free wiring and bidirectional protection
【DURABLE FOR USE】After the circuit breakers is disconnected, only reset is needed and there will be no damage
【EASY TO SEE】Built-in indicator window helps identify the contact position
【QUICK TO INSTALL】Easily install on the standard DIN rail with the buckle design
Rated Insulation Voltage: 1250V
Rated Operating Voltage: 250V
Rated Frame Current: 63A
Operating/Ultimate Short-Circuit Breaking Capacity: 6KA
Rated Impulse Withstand Voltage: 6KV
Mechanical Life: 20000 Times
Electrical Life: 10000 Times (<125VDC)
Rated Non-Tripping Current: 10.5A (≥1h)
Rated Tripping Current: 13A (<1h)
Rated Instantaneous Tripping Current: 60A (<0.1s)
Trip Mechanism: Thermal-Magnetic
Protection Rating: IP20
Damp Heat Resistance: Type 2
Operating Relative Humidity: ≤95%
Installation Method: DIN Rail
Recommended Terminal Torque: 17.7 inch·lbs~20.4 inch·lbs
