HTABOTEST HT206D Digital Clamp Meter T-RMS 6000 Counts, Multimeter Voltage Tester Auto-ranging, Measures Current Voltage Temperature Capacitance Resistance Diodes Continuity Duty-Cycle (AC/DC Curren)

The HT206D Digital Clamp Meter is a practical and reliable device that sports a vibrant red color and is constructed from durable ABS material. It comes equipped with an LCD display and features a 25cm mandibular opening, making it convenient for various electrical measurement tasks.This clamp meter offers a comprehensive range of measurement capabilities. For DC voltage, it can accurately measure within the range of 600mV/6V/60V/600V, with an accuracy of ±0.5% of the reading plus 5. The AC voltage can be measured within 6V/60V/600V, having an accuracy of ±1.0% reading plus 5. When it comes to current measurements, the AC current within 6A/60A/600A can be measured with an accuracy of ±2.5% of the reading plus 5, while the DC current capabilities are also available within relevant ranges. The resistance can be measured from 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ, with an accuracy of ±1.0% reading plus 5. It can also handle capacitance measurements for values such as 10nF/100nF/1μF/10μF/100μF/1mF/10mF/100mF. Additionally, the duty cycle can be measured within 1 - 99% and frequencies at 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz. It even has the ability to measure temperature within the range of -40~1000℃ / -40~1832°F. All these measurements have a maximum count of 6000, and the unit symbols are automatically displayed according to the measurement function gear.In terms of its operating environment, the working temperature and humidity should be within 0 - 40℃ (< 80%RH, < 10℃ non-condensing), while for storage, the temperature and humidity range is -10 - 60℃ (< 70%RH, with the battery removed). The maximum voltage between the terminal and the earth is 600V. The sampling rate is about 3 times/second, and when the measurement exceeds the range, it indicates “OL”. For continuity testing, the orange backlight turns on.Powered by 2 x 1.5V AAA batteries and weighing approximately 190 g, the HT206D Digital Clamp Meter is a useful and accurate tool for a wide variety of electrical measurement applications.it serves as an ideal Thanksgiving or Christmas gift for family and friends.
