1 Pair Black Red Solar Panel Extension Cable Wire PV Connector 12 AWG 5/10/20M
Key item features
- You will get brand new and high quality solar PV cable!
- This product is made of high quality materials, durable, can extend the service life, good wear resistance, energy saving, low cost!
- Cables and connectors are separate. You need to install them yourself. Only photovoltaic cables are sold.
- Nominal section: 4mm2 (12AWG)Details:Nominal section :4mm2 (12AWG)Model: PV1 - FRated current :70A (10AWG)Auditing: NO. 1Conductor: copper wire structure NO./mm 84/0.30Conductor stranded diameter :3.42mmInsulation (minimum wall thickness):0.5mmSheath (minimum wall thickness):0.5mmFinished wire diameter :6.9±0.1mmConductor resistance (20℃):≤ 3.39Ω / kmTest voltage kV/min: 6.5/5 without breakdownRated temperature :-40~+90 ° CMaximum conductor temperature :+ 120 ° CReference short-circuit allowable temperature :200 ° C for 5SService life :> 25 years (-40 ~ +90℃)Rated voltage: DC :1.8kv AC U/U: 0.6/1kvOperating ambient temperature :-40 ~ +90Operating voltage AC/DC (KV): 0.6 ~ 1.0/1.8Weather resistance: ultraviolet lightFlame retardant: single vertical combustion (IEC60332-1)Sun resistance test :HD605 / A1Ozone resistance test of finished cable :EN50396Smoke density :IEC61034, EN50268-2Halogen acid release :IEC670754-1 EN50267-2-1Waterproof grade: IP67Rated voltage :1000 vTest voltage :6 kv(50 Hz)Insulation material :PPOContact material: tinned copper, about 95% copper inside, about 5% tin outsideOperating temperature :-40°C to + 90°CSafety class: 2Class of flame: movement of UL94 - where V0Connector contact resistance ≤5 ΩInsertion and removal force ≤50 nWithdraw troops ≥50 nSize: 1 meter, 3 meter, 5 meter, 10 meter, 20 meter
Quantity: 1Pcs high quality solar photovoltaic cablePackage Contents:1Pcs high quality solar photovoltaic cableNotes:1. Due to various factors such as display brightness and light brightness, the actual color of the product may be slightly different from the picture displayed on the website.2. Please allow slight manual measurement deviation in the data.
Specs
How do you want your item?
About this item
Product details
Features:
* You will get brand new and high quality solar PV cable!
* This product is made of high quality materials, durable, can extend the service life, good wear resistance, energy saving, low cost!
* Cables and connectors are separate. You need to install them yourself. Only photovoltaic cables are sold.
* Nominal section: 4mm2 (12AWG)
Details:
Nominal section :4mm2 (12AWG)
Model: PV1 - F
Rated current :70A (10AWG)
Auditing: NO. 1
Conductor: copper wire structure NO./mm 84/0.30
Conductor stranded diameter :3.42mm
Insulation (minimum wall thickness):0.5mm
Sheath (minimum wall thickness):0.5mm
Finished wire diameter :6.9±0.1mm
Conductor resistance (20℃):≤ 3.39Ω / km
Test voltage kV/min: 6.5/5 without breakdown
Rated temperature :-40~+90 ° C
Maximum conductor temperature :+ 120 ° C
Reference short-circuit allowable temperature :200 ° C for 5S
Service life :> 25 years (-40 ~ +90℃)
Rated voltage: DC :1.8kv AC U/U: 0.6/1kv
Operating ambient temperature :-40 ~ +90
Operating voltage AC/DC (KV): 0.6 ~ 1.0/1.8
Weather resistance: ultraviolet light
Flame retardant: single vertical combustion (IEC60332-1)
Sun resistance test :HD605 / A1
Ozone resistance test of finished cable :EN50396
Smoke density :IEC61034, EN50268-2
Halogen acid release :IEC670754-1 EN50267-2-1
Waterproof grade: IP67
Rated voltage :1000 v
Test voltage :6 kv(50 Hz)
Insulation material :PPO
Contact material: tinned copper, about 95% copper inside, about 5% tin outside
Operating temperature :-40°C to + 90°C
Safety class: 2
Class of flame: movement of UL94 - where V0
Connector contact resistance ≤5 Ω
Insertion and removal force ≤50 n
Withdraw troops ≥50 n
Size: 1 meter, 3 meter, 5 meter, 10 meter, 20 meter
Quantity: 1Pcs high quality solar photovoltaic cable
Package Contents:
1Pcs high quality solar photovoltaic cable
Notes:
1. Due to various factors such as display brightness and light brightness, the actual color of the product may be slightly different from the picture displayed on the website.
2. Please allow slight manual measurement deviation in the data.
