BE-TOOL 4 Flute Milling End Cutter Drill Bit for CNC Cutter Milling Drill Bit Metal Tool 12mm Silver

Features:

The Mill Cutter is usually assembled on milling machine;

Suitable for CNC data processing center, carved and high-speed machines;

Can mill copper, aluminum, tool steel, cast iron, etc.

High toughness, abrasion resistance, and high-speed cutting for the high hardness;

Can directly processing or fine processing to the heat treatment mold;

Reduce the frequency of tool changes, improve machine actuator movement rhythm, save mold making time.

Specifications:

Material: HSS-AL

Model: about 3/ 4/ 5/ 6/ 8/ 10/ 12 mm (0.11/ 0.16/ 0.20/ 0.24/ 0.32/ 0.39/ 0.47 in)

Size: (approx.) cutting diameter* shank diameter* shank length* overall length

1) 3*6*8*52 mm / 0.11*0.24*0.31*2.05 in

2) 4* 6*11*55 mm / 0.16*0.24*0.43*2.17 in

3) 5*6*13*57 mm / 0.20*0.24*0.51*2.16 in

4) 6*6*13*57 mm / 0.24*0.24*0.51*2.24 in

5) 8*8*19*63 mm / 0.31*0.31*0.75*2.48 in

6) 10*10*22*72 mm / 0.39*0.39*0.87*2.83 in

7) 12*12*26*83 mm / 0.47*0.47*1.02*3.27 in

Package List:

1 x 4-Flute Milling End Cutter Drill Bit
