KAKA INDUSTRIAL FNL-100B Horizontal vertical collet index

FNL 100B can be mounted on milling machine, grinding machine, drilling machine and other machine tools. The divisions of 2,3,4,6,8,12,and 24 can be divided. It can also be used for marking out of components.

This index has the advantage of use in horizontal and vertical, compact construction, light in weight, operating by single handle, It can accept a 5C collet. Consequently, it is a reliable device for enhancing work efficiency.

Accessories

Hex wrench (4mm、8mm 1 piece each)Socket hexagon  100

Specifications

items      FNL100B

Center height mm 101.6

Min.ID of spindle mm   31.75

Divisions 2.3.4.6.8.12.24

Spindle screw 24x8

Can be equipped with elastic chuck:  5C

Dividing accuracy: individual spacing error:±3”

Net weight (lb)28

Gross weight(lb)    33

Case dimensions(in) 12x10x11
