Pass & Seymour Ivory Commercial Receptacle Outlet Duplex 20A 125V CR20-I

Pass & Seymour Straight blade duplex receptacle in ivory color features a thermoplastic body and nylon face material for impact as well as rust resistance. Commercial grade receptacle comes with zinc-plated steel assembly and drive screws. It can withstand minimum dielectric voltage of 2000 Volts. The 2-Pole receptacle comes with 0.032-Inch thick brass triple-wipe line contacts for longer service life and fast/easy split-circuit wiring. Receptacle has current rating of 20 Amps and a voltage rating of 125 Volts. It measures 1.322 Inch x 1.018 Inch x 3.281 Inch.Receptacle has side wired connection for added convenience and can accommodate a wire of size 14 - 10 AWG. It features tri-drive, backed-out terminal screws that reduce installation time and has three-wire circuitry. It has size 8 tri-drive steel terminal screws, size 8 hex tri-drive steel grounding screw, auto-ground clip and 5-20R NEMA configuration. It has a rated UL 94 V-2 flammability and operates at -40 to 50 deg C temperature. The auto-ground feature eliminates the necessity to terminate grounding conductor to device. Receptacle is UL 498 listed/CSA certified. Also known as -Pass & Seymour CR20-I Double Pole Straight Blade Duplex Receptacle Wall Mount 1-P & S CR20-I Commercial Spec Grade Duplex Receptacle, 20A 125V, 5-20R, Ivory-Pass & Seymour Cr20-i Cr20-i Commercial Side Receptacle (cr20i)
