Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High and Low Level H/L Level Trigger Module Triggered Compatible with Arduino Raspberry Pi

(No ratings yet)

Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High and Low Level H/L Level Trigger Module Triggered Compatible with Arduino Raspberry Pi Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High Low Level H L Level Trigger Module Triggered Compatible Arduino Raspberry Pi Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High Low Level H L Level Trigger Module Triggered Compatible Arduino Raspberry Pi Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High Low Level H L Level Trigger Module Triggered Compatible Arduino Raspberry Pi Treedix DC 5V Channel Relay Board Module Isolated Optocoupler High Low Level H L Level Trigger Module Triggered Compatible Arduino Raspberry Pi

Size:4 Channel

Key item features

Input voltage: DC 5V, normally open interfaces, the max load of interface is AC 250V/10, DC 30V/10A.
SMD optocoupler isolation, strong driving ability, stable performance; trigger current 5mA.
With green power light, red relay status indicator light, can reflect the module's working condition directly.
The Module can be set by jumper high or low trigger.

Specs

Amps
10 Amps
Input voltage
5 V
Brand
TREEDIX
Size
4 Channel

Current price is $8.99

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives between May 29 - Jun 5

Sold and shipped by Treedix

3.652173913043478 stars out of 5, based on 23 seller reviews(3.7)

Report an issue with this seller

Free 30-day returns

About this item

Product details

Maximum load: AC 250V/10A, DC30V/10A
SMD optocoupler isolation, strong driving ability, stable performance; trigger current 5mA
The module voltage 5V
Each channel module can be set high or low triggered by jumper
Fault-tolerant design, even if the control line is broken, the relay will not operate
Power indicator (green), relay state indicator (red)
Interface design user-friendly, all interfaces are available through the wiring terminal direct connection leads, very convenient
4 mounting bolts holes, hole 3.1mm, spacing 44.5mm * 35.5mm
Module Port:
DC+: DC power supply positive
DC-: DC power supply negative
IN1: Channel 1 signal trigger terminal
IN2: Channel 2 signal trigger terminal

Relay Output:
NC1: Channel 1 relay normally closed pin
COM1: Channel 1 relay common pin
NO1: Channel 1 relay normally opened pin
NC2: Channel 2 relay normally closed pin
COM2: Channel 2 relay common pin
NO2: Channel 2 relay normally opened pin

High And Low Level Trigger Option:
1. S1: It is option switch for channel 1 relay
2. S2: It is option switch for channel 2 relay

Package include:
2 x DC 5v 2 Channel Relay Board Modules

Input voltage: DC 5V, normally open interfaces, the max load of interface is AC 250V/10, DC 30V/10A.
SMD optocoupler isolation, strong driving ability, stable performance; trigger current 5mA.
With green power light, red relay status indicator light, can reflect the module's working condition directly.
The Module can be set by jumper high or low trigger.
