TOOL1SHOoo 10T Hydraulic Cylinder Bottle Jack Single Acting Low Profile Porta Power Ram
Key item features
- Stop Ring:There Is a Stop Ring Under the Spindle That Can Play a Protective Role When the Spindle Is Raised to Prevent Breakage and Damage.It Is Safer for You to Use It.
- On/off Knob:There Is a Knob on the Pump Head for Controlling the Jack.Tune It to off to Lift the Jack.When Tuned to on,the Jack Will Restart.This Knob Can Make the Operation More Convenient and Safer.
- Chrome-plated Surface:the Surface of the Spindle Is Chrome-plated,Which Makes It Smoother and Can Extend the Service Life of the Spindle.
- Convex Pattern:the Handle of the Pump Has a Convex Pattern Design,Which Can Play a Good Anti-slip Effect.You Can Grip It More Firmly When Using It,Providing Better Force.
- Application:It Is Often Used in Power,Chemical,Steel,Bridges and Other Industries.It Is Suitable for Railway Vehicle Maintenance,Mechanical Installation,Construction Engineering Support,Etc.
- Notes:
Please Use This Item on Hard and Flat Ground.
Please Do Not Exceed the Load Capacity of the Jack.
- Warm Tips
1.Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
2.100% Quality Assurance:We ship directly from the US warehouse. Feel free to contact us if you have any questions. We will provide the best suitable solutions for you. We are committed to provide best service for every customer!
- TOOL1SHOoo COLLECTION is a professional tool and equipment company aiming to provide quality products and services. If you have any problems, please feel free to contact us and we will reply to your in 24 hours.
Specs
- Max load10 Tons
- Maximum lift5.98 in
- Lifting jack typeBottle Jack
- FeaturesLow Profile
- BrandTOOL1SHOoo
- MaterialStainless Steel
- Free shipping
Free 30-day returns
(Only one option can be selected at a time)
How do you want your item?
About this item
Product details
【Product Description】
This TOOL1SHOoo Manual Hydraulic Jack Is Made of High-quality Steel,Which Is Strong,Durable and Not Easy to Deform.It Has a Load Tonnage of 10t/22.46.22 Lbs.You Need to Press the Pump Handle to Jack up Heavier Items Easily.This Manual Hydraulic Jack Is Very Labor-saving and Convenient to Use.It Is Also a Good Helper When You Work.
【Specifications】
- Jack Body Height:10.2cm/4.02"
- Jack Extended Height:15.2cm/5.98"
- Jack Size:14*7.5*10cm/5.6*3*4"
- Jack Weight:2.5kg/5.51 Lbs
- Pump Weight:3kg/6.61 Lbs
- Gross Weight:6.5kg/14.33 Lbs
- Package Size:38.5*22.5*17cm/15.16*8.86*6.7"
- Specifications
- Color:Yellow+Black
- Jack Model:Rsc-1050
- Pump Model:Cp-180
- Product Material:Steel
- Oil Pipe Material:Rubber
- Surface Treatment:Spraying
- Spindle Surface Treatment:Chrome Plated
- Jack Load Tonnage:10t/22.46.22 Lbs
- Jack Stroke:5cm/1.97"
- Jack Oil Storage Capacity:72cc
- Pump Max Pressure:70 Mpa
【How to Use】
Open the Interface Cover of the Jack to Connect with the Pump's Oil Pipe Interface and Tighten the Screw.
Turn the Knob of the Pump to off.
Place the Jack Under the Object to Be Lifted and Press the Pump Handle up and down to Start Working.
After the Object Is Lifted,Turn the Knob to on,and the Jack Will Restart.
【Package Included】
1*Hydraulic Jack
1*Pump
1*Oil Pipe
【Key features】
Large load tonnage——the high hardness material of the jack enables it to load a tonnage of 10t/22.46.22 Lbs,which is enough to lift many items to meet your work needs.
Robust and durable——The jack and pump are made of high hardness and high quality steel materials and have been sprayed with surface treatment.This makes the project not easy to rust,very durable and long service life.
Ergonomic design——The handle of the pump is a very ergonomic design.It is smoother and more comfortable to hold when working.
High safety——the anti-slip ring on the main shaft can ensure that the placed items are more stable.The stopper ring can prevent the jack from breaking and damaging during loading.
Anti-leakage and dust-proof——the interface part of the jack is a threaded Zg3/8 joint with a steel ball inside to prevent reverse oil leakage.
Multi-angle use——you can select the vertical,horizontal or inverted placement direction according to the space requirements.All these angles can achieve improvement.
Easy to operate——you need to connect the jack and the pump,then hold the pump handle,press and put down to lift the object.This is very easy to operate.
High stability——there are support feet on both sides of the pump to make it more stable.It will not shake freely during use.
