Maxpeedingrods S400S062 Turbocharger for Int Harvester Truck with Series 60 Engine 2000-2008

Applications:

for DDC-MTU Truck with Series 60 Engine 2000-2008

for Navistar Truck with Series 60 Engine 2000-2008

for Int Harvester Truck with Series 60 Engine 2000-2008

for 4.0L-6.0L Car engine

Replacement & Part Number:

171702,  171703,  171691,  171701,  23518588

23518567,  23518597,  23523197,  2585838C91

S400SX4,    S475,   S400,  T6

Specification:

Turbine:

Turbine Inducer: 95.7mm

Turbine Exducer: 88.1mm

Turbine Trim: 84.7

Turbine Wheel: 10 Blades

Turbine Exhaust Inlet: Twin Scroll T6 Flange

Turbine Exhaust Outlet: 5″ for Marmon S400

Compressor :

Compressor Inducer: 74.5mm

Compressor Exducer: 107mm

Compressor Trim: 48.5

Compressor Wheel: 7+7 Blades

Compressor air inlet: 5.00" ported anti-surge

Compressor Air Outlet: 4.21" charge pipe outlet

Oil Inlet: 1/4"-19 & M8H

Oil Outlet: 2*M8*1

Wastegate: W/O Wastegate

Turbo Model: S400S062

Engine Code: Series 60

Cooling Type: Oil Cooling

Bearing Type: Journal Bearing

Thrust Bearing: 270 degree

Hosepower: 500-1050 HP

Turbo Type: Twin Scroll

Features:

*Product Material

1. Turbine housing:  Ductile iron QT450-10 - temperature resistant up to 700℃

2. Steel turbine wheel:  K418 alloy -  high  oxidation stability and resistance  up  to 900℃

3. Compressor housing:  ZL104 aluminum with lightweight

4. Compressor wheel/blades:  Cast aluminium blades – superior air tightness & corrosion resistance

* Technology Advantage:

1. 100% balancing Test by TURBOTECHNICS  VSR3

2. G3-min-Flow VNT Turbo testing

3.  Advanced Actuator Tester/Programmer
