SENRISE Soldered DSO138 2.4" TFT Digital Oscilloscope DIY Module(1Msps) + Probe AS

Features:

-This kit uses ARM Cortex-M3 processor (STM32F103C8), and includes a 2.4-inch color TFT display screen, can be used as ARM test development board.
-Can be secondary development on the basis of this kit, for example, it can be changed to Millivoltmeter, data loggers.
-Adjustable vertical displacement, and with instructions.
-With automatic, regular and one-shot modes, easy to capture the moment waveform.
-Available rising or falling edge trigger.
-Observable previous trigger waveform (negative delay).
-Can freeze at any time waveform display (HOLD function).
-Comes 1Hz /3.3V square wave test signal source.
-With waveform parameter digital display, including frequency, period, pulse width, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values.
-Waveform storage function: will not lose the waveform after power off.
-Short-circuit and open-circuit detection: can help the user find out the soldering error.
-TFT controller recognition function.

Specifications:

Maximum Real-time Sampling Rate: 1Msps
Accuracy: 12Bit
Sampling Buffer Depth: 1024 bytes
Analog Bandwidth: 0-200KHz
Vertical Sensitivity: 10mV / Div - 5V / Div (1-2-5 progressive manner)
Input Impedance: 1MΩ
Maximum Input Voltage: 50Vpp (1: 1 probe), 400Vpp (10: 1 probe)
Coupling Modes: DC / AC / GND
The Horizontal Time Base Range: 10μs / Div - 50s / Div (1-2-5 progressive manner)
Supply Voltage: DC 9V
PCB Size: 117 * 76mm / 4.6 * 3in
Screen Size: 52 * 40mm / 2 * 1.57in
Package Size: 18 * 12.5 * 3cm / 7.08 * 4.92 * 1.18in
Package Weight: 119g / 4.21oz

Package List:

According to your choise.
