1PC Receiver Module With DCF Antenna 77.5KHz Single Frequency Module Radio Time Module Radio For-Arduino Module Single Frequency

Hero image 0 of 1PC Receiver Module With DCF Antenna 77.5KHz Single Frequency Module Radio Time Module Radio For-Arduino Module Single Frequency, 0 of 11

Sufanic

1PC Receiver Module With DCF Antenna 77.5KHz Single Frequency Module Radio Time Module Radio For-Arduino Module Single Frequency

(No ratings yet)

Key item features

【Complete Time Synchronization】This DCF receiver module is tuned to the time signal transmitter DCF77 ( for Frankfurt 77.5 kHz) and utilizes an antenna for signal reception, amplification, and demodulation. The MCU then accurately identifies and synchronizes the date and time from the timing center, complete time synchronization.
【Compact Design】The PCB size of this module is 21.5x13.5x1.0mm, and the antenna size is AR10x60mm. Its small footprint allows for easy integration into various applications while maintaining efficient performance.
• Receiving frequency: 77.5 KHz* • Board size (without antenna) LxWxH: 22x13.5x1 mm* • Antenna quality: LxØ: 60x10mm* • Scope of delivery: 1 piece* ⇒ DCF receiver module with antenna***
***Technical Specifications*Product number: DCF-1060N-800*RCCM category: DCF/77.5KHz single frequency module*PCBA size: 21.5x13.5x1.0mm/FR4*Antenna size: AR10x60mm/High Q*Nominal frequency: 77.5KHz±300Hz*
**Note: Single-frequency modules cannot be switched between different frequencies of DCF/WVB/HBG/BPC, for JJY dual-frequency modules can be switched between 40K/60K two frequencies, to make a certain single-frequency module, only can receive signals in this frequency band.***Package Included:*1*Receiver module***

Specs

Brand
Sufanic
Height
2.36 in

Current price is Now $12.79

You save $2.80

was $15.59

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives between Jul 8 - Jul 13

Sold and shipped by Ylsvt

3.92156862745098 stars out of 5, based on 51 seller reviews(3.9)

Free 30-day returns

About this item

Product details

describe:

DCF receiver module with DCF antenna tuned to time signal transmitter DCF77 ( for Frankfurt 77.5 kHz). The antenna induction signal is sent to the IC for amplification, demodulation, and then identified by the MCU, so that the date and time of the timing center are completely consistent.

Below you will find important setup and circuit diagrams.

Technical Specifications

Product number: DCF-1060N-800

RCCM category: DCF/77.5KHz single frequency module

PCBA size: 21.5x13.5x1.0mm/FR4

Antenna size: AR10x60mm/High Q

Nominal frequency: 77.5KHz±300Hz

Sensitivity: 26±2dB

Receiving IC: SP6007

• Operating voltage: 1.1...3.3 V

• Current consumption: 85 µA max

• Receiving frequency: 77.5 KHz

• Board size (without antenna) LxWxH: 22x13.5x1 mm

• Antenna quality: LxØ: 60x10mm

• Scope of delivery: 1 piece

⇒ DCF receiver module with antenna

• connect:

⇒ Ground = Pin

⇒ Operating Voltage = Pin V

⇒ = pin T

⇒ Power On/Off = Pin P1

• Important note:

⇒ PIN P1 is an on/off switch and must be set to logic low.

Note: Single-frequency modules cannot be switched between different frequencies of DCF/WVB/HBG/BPC, for JJY dual-frequency modules can be switched between 40K/60K two frequencies, to make a certain single-frequency module, only can receive signals in this frequency band.

Package Included:

1*Receiver module

【Complete Time Synchronization】This DCF receiver module is tuned to the time signal transmitter DCF77 ( for Frankfurt 77.5 kHz) and utilizes an antenna for signal reception, amplification, and demodulation. The MCU then accurately identifies and synchronizes the date and time from the timing center, complete time synchronization.
【Compact Design】The PCB size of this module is 21.5x13.5x1.0mm, and the antenna size is AR10x60mm. Its small footprint allows for easy integration into various applications while maintaining efficient performance.
• Receiving frequency: 77.5 KHz* • Board size (without antenna) LxWxH: 22x13.5x1 mm* • Antenna quality: LxØ: 60x10mm* • Scope of delivery: 1 piece* ⇒ DCF receiver module with antenna***
***Technical Specifications*Product number: DCF-1060N-800*RCCM category: DCF/77.5KHz single frequency module*PCBA size: 21.5x13.5x1.0mm/FR4*Antenna size: AR10x60mm/High Q*Nominal frequency: 77.5KHz±300Hz*
**Note: Single-frequency modules cannot be switched between different frequencies of DCF/WVB/HBG/BPC, for JJY dual-frequency modules can be switched between 40K/60K two frequencies, to make a certain single-frequency module, only can receive signals in this frequency band.***Package Included:*1*Receiver module***
