EATON BUSSMANN Fuse,60A,Nonindicating,MAX,32VDC MAX-60

A fuse consists of a low resistance metallic wire enclosed in a non-combustible material which serves to protect a circuit from overload. Here are some important details for Eaton Bussmann Fuse. Length: 1-7/10", Fuse Amps: 60A, Width: 1-7/32".

Features

• Standards: RoHS 2002/95/EC
• Indicating / Nonindicating: Nonindicating
• Fuse Interrupt Rating: 1kA at 32VDC
• Green Environmental Attribute: RoHS 2011/65/EU Compliant
• Fuse Amps: 60A
• Fuse Voltage Rating: 32VDC
• Diameter: Not Applicable
• Width: 1-7/32"
• Body Material: plastic
• Rejection / Nonrejection: Nonrejection
• Fuse Speed: Fast Acting
• Color Code: Blue
• Length: 1-23/64"
• Series: MAX
• Element: Single
• Functionally Equal To: Littelfuse MAX, Mersen/Ferraz Shawmut AF-3
• Depth: 23/64"
• Item: Automotive Fuse
• Body Style: Blade
• Interrupt Rating: 1kA at 32VDC
• Speed: Fast Acting
• Equivalent Brand and Series: Bussmann MAX, Littelfuse 299, Mersen AF3
• Fuse Size: 1-23/64" L x 1-7/32" W x 23/64" D
• Compatible Fuse Block Series: HHX, MAX
• Visual Indication: Nonindicating
• Amps: 60A
• Fits Fuse Block Style: Nonrejection
• AC Voltage Rating: Not Rated
• Equivalent Series: 299, AF3, MAX
• DC Voltage Rating: 32VDC
