TUF-2000M TS-2 Digital Ultrasonic Flowmeter Flow Meter Ultrasinic Flow Module/RTU with TS2/TM1 sensor (DN15-100mm) -30 ~ +90C ,Stable Performance

Features

Description

High accuracy Linearity: better than 0.5%, Repeatability: better than 0.2%, Accuracy: better than +-1%

Wide measuring range Several types transducer for selection, pipe size from DN15mm to DN6000mm

Far transmission distance Connecting module and secondary meter through RS-485 interface, transmission distance up to 1000m

Powerful Functions Current output: 4-20mA, one channel, can be used for flow/heat transmitter;

OCT output: two channels, can be used for flow /heat switch;

Current input: 4-20mA, three channels, can be used for data collector;

Tri-wire resistance signal input (PT100): two channels, can be used for calorimeter.

Wide Application

Its unique features, particularly low cost, small size, high performance, local display, make it the ideal choice for industrial automation, processing control, flow meter networking, composing multi-channel, high accuracy flow meter.

Structure of Unified Calorimeter:

Standard Packing List:

Transmitter 1 set

TM-1 type transducer 1 pair

Clamp Fixture 1 set

5m×2 Transducer Cable 1 pair

English User Manual 1 piece (electronic
