Uxcell T-Slot Bolts, Drop-in Bolt Hammer Head with Hexagon Flange Nuts T-Bolt Stud Sliding Screw for Aluminum Profile M5x25mm

The T-slot drop-in bolt is fastened with nuts between aluminum profiles and accessories. It is commonly used in aluminum alloy rack assembly, T-slot tracks, furniture assembly, and paper machines. It is also widely applied in lifting, metallurgy, mechanical equipment, power mechanical equipment assembly, and fixed mechanical equipment assembly and debugging.

Specification
Color: Silver
Material: Carbon Steel Nickel Plated
Thread Diameter: M5
Thread Length: 23 mm / 0.91 Inch
Screw Length: 28.5 mm / 1.12 Inch (excluding the thickness of the head)
Head Size: 10.3 x 6 x 3.5 mm / 0.41 x 0.24 x 0.14 Inch (L*W*THK)
Step Size: 1.8 x 6 mm / 0.07 x 0.24 Inch (H*W)
Packing List: 1 Set x T-Slot Bolts with Hexagon Flange Nuts (20 x T-Slot Bolts, 20 x Hexagon Flange Nuts)

Advantages
The T track bolt is crafted from excellent carbon steel nickel plated and boasts excellent rust resistance and durability. Its high hardness, wear, corrosion, and oxidation resistance enhance its longevity, ensuring it provides robust rust protection for long-lasting durability. This essential jig and fixture hardware simplifies customization and is designed with precision-machined t-heads for easy fitting into grooves and t-slots. It offers robust torque resistance, preventing stripping or over-tightening during heavy usage.

Instruction
Easy to install. Insert the screw head into the profile groove and rotate it 90 degrees to secure it in place.

NOTE:
Before purchasing, confirm that the size of your aluminum profile or T-groove aligns with our T-bolt and ensure the step height does not exceed the profile wall thickness.
