Garmin 010-01307-13 Garmin Gpsmap 7612Xsv

Garmin GPSMAP 7612xsv J1939 Combo
Brand New Includes One Year Warranty

010-01307-13 - (GPSMAP 7612xsv J1939) 010-01966-00 - (Garmin GT51M-TM)

The Garmin GPSMAP 7612xsv J1939 Transducer Bundle chartplotter with 12" multi-touch widescreen is designed for powerboat users, sailors and racing sailors. It has built in J1939 connector which offers a dedicated CAN port for receiving engine data. The chartplotter has advanced sailing and sail racing features, that include laylines, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider. Gauge displays show true and apparent wind angle, set and drift, true or apparent wind speed, horizontal or vertical graphs.

The GPSMAP 7612xsv J1939 Transducer Bundle features a 10 Hz GPS/GLONASS receiver that updates position and heading 10 times per second. The device offers dual-channel 1kW CHIRP, plus DownV? and SideV? sonar scanning with CHIRP technology and is fully network capable for Garmin Marine Network and NMEA 2000®.

GPSMAP 7612xsv J1939 Transducer Bundle Features:

• GPS Chartplotter Transducer Bundle
• GPSMAP J1939 w/ Worldwide Basemap
• Built in J1939 Connector Offers Dedicated CAN Port
• 12" WVGA Multi-touchscreen
• 10Hz GPS/GLONASS Receiver
  -Updates Position & Heading Up To 10 Times Per Second
• Garmin Marine Network & NMEA 2000 Support
• Advanced Sailing & Sail Racing Features
• Built-in Dual CHIRP Sonar Technology
• DownV?™ & SideV?™ Scanning Sonar
• Supports GSD™ 26 Professional Sonar Module
• Preloaded BlueChart® g2 U.S. & LakeV?™ HD Map
• 5000
• Routes: 100
• Track Log: 100
• 2 Micro SD Card Slots
• View & Control from a Smartphone or Tablet
• Internal Antenna w/ External Connection
• Compatible w/ gWind™ Transducers
• FUSION-Link Entertainment System
• Built-in Wi-Fi/ANT+™
• Sonar Features:
  - Garmin Sonar Compatible
  - Dual-frequency (50/200 kHz) Sonar Capable
  - Dual-beam (77/200 kHz) Sonar Capable
  - Bottom Lock
  - Water Temperature Log & Graph
  - Sonar Recording
  - Sonar History Rewind
• Supported Sailing Features:
  - Laylines
  - Enhanced Wind Rose
  - Heading & Course-over-Ground Lines
  - True Wind Data Fields
  - Tide/Current/Time Slider
• Gauge Displays:
  - True & Apparent Wind Angle
  - Set & Drift
  - True or Apparent Wind Speed
  - Horizontal or Vertical Graphs
  - Data Bar w/ Customisable Data Fields
• Garmin Radar Compatible
• NMEA 0183 Compatible
• Garmin SmartMode Compatible
• Supports AIS
• Supports DSC
• Tide Tables
• Garmin Meteor Audio System Compatible
• SiriusXM™ Weather & Radio compatible
• BlueChart® Mobile (planning) Compatible
• GRID™ (Garmin Remote Input Device) compatible
• Wireless Remote Compatible
• Auto Backlight Dimming
• Supplemental Map Sharing
• Internal Sonar Sharing: Transmit & Receive
• Bail, Flat or Flush Mounting Options
• IPX7 Water Rating
