GREENFIELD THREADING 289459 Thread Forming Tap, #10-32, Bottoming, Bright, 0 Flutes

Thread Forming Tap, Thread Size #10-32, UNF, Overall Length 2 3/8 in, High Speed Steel, Bright (Uncoated), Right Hand, Thread Length 1/2 in, 75 Percent Thread Drill Size 4.40mm, Thread Limit H6, Class of Fit 2B-3B

Features

• Overall Length: 2-3/8"
• Shank Dia.: 0.194"
• Tap Grouping: Tap
• Tap Material: High Speed Steel
• Pitch Diameter Limit: H6
• Tap Dimension Type: Inch
• Tap Thread Size: #10-32
• Standards: USCTI Table 302A
• List Number: FTGP
• Tap Size: #10
• Thread Length: 1/2"
• Tap Style: Thread Forming
• Number of Pieces: 1
• Item: Thread Forming Tap
• Tap Thread Type: UNF
• Tap Chamfer: Bottoming
• Tap Finish: Bright
• Number of Flutes: 0
• Thread Direction: Right Hand
• Cutting Direction - Machining: Right Hand
• Primary Material Application: Aluminum, Brass, Bronze, Copper, Steel
• Threads per Inch: 32
• Thread Size: #10-32
• Thread Standard: UNF
• Material Grade - Machining: FTGP
• Series: FTGP
• Primary Material Application ISO Code: N, P
• Square Size: 0.1520 in
• Class of Fit: 2B-3B
• Extended Neck: Yes
• Shank Length: 1 1/2 in
• Spiral Direction: Neutral
• Thread Limit: H6
